Saitek X45 - Page 2

Throttle
(Reverse Angle)
2 x Rotary Controls
4-way Hat Switch
Rudder Control
Throttle Rudder System
2 x Fire Buttons
4-wayHat Switch
Throttle Control with Detents
Rudder Control
2 x Rotary Controls
Mouse controller/8-way Hat
Switch
3 x Mode Status LEDs
Control Commands
on Base
Joystick Head
'Pinkie' LED Indicator
Missile Launcher
2 x 8-way Hat Switch
Joystick
4 x Fire Buttons
Missile Launcher
2 x 8-way Hat
Switches
Pinkie Switch
Control Commands
on Base
