Saker RapX - Overview Saker; Dimensions Saker Sniper; Overview Engine Compartment

7
DIMENSIONS SAKER SNIPER.
8
OVERVIEW ENGINE COMPARTMENT.
1. Engine oil 4. Fuel pump 7. Drive shaft 10. Exhaust 13. Oil filter
2. Engine dipstick 5. Starter engine 8. Clutch release lever 11. Gearbox dipstick 14. Oil cooler
3. Ignition coil 6. Intercooler 9. Gearbox 12. Turbo 15. Coolant
