1.5 mm
1.5 mm
Rotate the white wheel towards the back of the drawer to adjust right.
This operation is tool free.
Rotate the white wheel towards the drawer frontal to adjust left.
This operation is tool free.
For sideways adjustment, it is recommended that the adjusters on the clips are operated in the same direction, in order to maintain
the correct alignment and movement of the runners.
Sideways adjustment +/- 1,5 mm
18
