SALICE F70 - Depth Adjustment (+;- 3 mm)

+ 3 mm
- 3 mm
Rotate the white wheel towards the inside of the drawer to reduce the gap between the frontal and the side.
This operation is tool free.
Depth adjustment +/- 3 mm
Rotate the white wheel towards the outside of the drawer to increase the gap between the frontal and the side.
This operation is tool free.
19
