SALICE F70 - F70 Push Synchronizer System; Synchronizer Product Features; Bar Cutting Technical Information

X (1305 mm MAX)
(X - 155 mm) ±1
75 mm MIN 75 mm MIN
13 mm MAX
(X - 155 mm) ±1
X
F70 Push synchronizer
The synchronisation system for Push-open F70 runners has been developed to ensure that drawers of any width
can be opened with minimum effort.
The system links the two runners, which thus become a single element; a pressure at any point of the drawer
frontal (even at the extremities), is sufcient for the Push mechanism to release and consequently for the drawer
to self-open.
The synchroniser can be used with any drawer width; its functionality is at its best with wider drawers.
It can be used on drawers of any width; however, it is recommended for drawers over 80 cm in width.
PRODUCT FEATURES:
- perfectly silent sliding movement
- available on all runner lengths
- min. width of the cabinet (X) = 280 mm
- max. width of the cabinet (X) = 1305 mm
- bar length = 1150 mm (to cut to length)
Technical information - Formula for cutting the bar to length
X = Internal width of the cabinet
The assembly of the synchroniser requires a minimum 75 mm groove in the rear of the drawer
