97
95 Min.
6
51 23
111
59 23
7
Front locking devices - Side and depth adjustments
- Dual steel/ber glass-nylon construction
- Compatible with all Progressa runners
- Tool free lateral and depth adjustments
- Pre-drilling recommended ø 2.5 mm
For all Progressa, Progressa
+
and Progressa
+
Shelf runners
AFCGXX3B
PACKING
2 boxes = 100 pcs right and 100 pcs left
Assembly to the bottom Assembly to the drawer
Use drilling templates ASGD704U3XA for accurate installation of the clips, see page 65.
Fix with screws,
as indicated
(recommended screws
ø 4 x 16 mm)
Fix with screws,
as indicated
(recommended screws
ø 4 x 16 mm)
