76 mm MIN 76 mm MIN
13 mm MAX
X (Max. 1305 mm)
X
Progressa Push Synchronizer bar
The synchronization system for Progressa Push, Progressa
+
Push and Progressa
+
Shelf Push runners has
been developed to ensure that wider drawers can be opened with minimum effort, regardless of where pressure
is applied.
The system links the two runners, which then become a single element; applying pressure on any part of the
drawer front (even at the extremities), is sufcient for the Push devices to release and consequently for the
drawer to open.
The synchronization can be used with any drawer width; its functionality is at its best with drawers wider than
800 mm.
PRODUCT FEATURES:
- smooth and progressive running action
- runner load capacity remains unchanged
- available on any Progressa Push, Progressa
+
Push and Progressa
+
Shelf Push drawer length
- minimum opening (X) = 280 mm
- maximum opening (X) = 1305 mm
- bar length = 1150 cut to size
Technical information - Formula for cutting the bar to length
X = Internal width of the cabinet
The assembly of the synchronizer requires a minimum 76 mm notch in the rear of the drawer
BAR LENGTH
For 13 mm to 16 mm drawer material = (X - 155) ±1
For 18-19 mm drawer material = (X - 163) ±1
BAR LENGTH
For 13 mm to 16 mm drawer material = (X - 155) ±1
For 18-19 mm drawer material = (X - 163) ±1
