Salto XS4-Locker - Mounting Options and Door Preparation; Dimension B Explanation; R and L Mounting Types

All contents current at time of publication.
SALTO Systems S.L. reserves the right to change availability of any
item in this catalog, its design, construction, and/or materials.
220639 -ED0 -27/09/2012
European view
© 2011 SALTO Systems S.L.
Installation guide XS4-Locker
2/4
B
B
B
The dimension B will depend on the door or strike tipe the locker lock is going to be installed on.
La cota B dependera en cada caso del tipo de puerta o cerradero donde se instale la cerradura de taquilla .
La mesure B dépendra dans chaque cas du type de porte ou gâche où va s'intaller la serrure vestiaire.
Moß B ist abhängig von Tür-oder Schließblechart, an der das Schrank-/Kabinenschloss installiert wird.
OUTSIDE
B
=
=
¡clik!
B
"R" MOUNTING
MONTAJE "R"
MONTAGE "R"
"L" MOUNTING
MONTAJE "L"
MONTAGE "L"
Eng
F
D
E
R
L
INSIDE
7 mm [1/4"] deep, Hole only inside.
Agujero solo por el interior. 7 mm de prof.
Trou de 7 mm profondeur par l'interieur.
7mm tiefe Lochung nur innen.
O
3
[
1
/
8
"
]
EXTERIOR
EXTERIEUR
AUSSEN
ESTERNO
INTERIOR
INTERIEUR
INNEN
INTERNO
