Resistance
Range
Resolution
Accuracy
Open Circuit Volts
660Ω
0.1Ω
± (1.0% rdg + 5d)
-3.5V dc
6.6kΩ
1Ω
± (1.0% rdg + 5d)
-1.1V dc
66kΩ
10Ω
± (1.0% rdg + 5d)
-1.1V dc
660kΩ
100Ω
± (1.0% rdg + 5d)
-1.1V dc
6.6MΩ
1kΩ
± (2.0% rdg + 5d)
-1.1V dc
66MΩ
10kΩ
± (3.5% rdg + 5d)
-1.1V dc
Overload protection: 600V DC or AC rms
Continuity Test
Range
Audible Threshold
Response Time
Open Circuit Volts
660Ω
Less than 30Ω
Approx. 100ms
-3.5V dc
Overload protection: 600V DC or AC rms
Diode Test
Range
Resolution
Accuracy
Test Current
Open Circuit Volts
2V
1mV
±(1.5% rdg +5d)
0.8mA
3.2V dc typical
Audible indication: Less than 0.03V
Overload protection: 600V DC or AC rms
Capacitance
Range
Resolution
Accuracy
6.6 nF
66 nF
660 nF
6.6 µF
66 µF
660 µF
6.6mF
1PF
10PF
100PF
1nF
10nF
100nF
1μF
±(3.0% rdg + 30d)
±(3.0% rdg + 10d)
±(3.0% rdg + 30d)
±(3.0% rdg + 10d)
±(3.0% rdg + 10d)
±(3.0% rdg + 10d)
±(5.0% rdg + 10d)
Overload Protection: 600V DC or AC rms
%Duty Cycle
Range
Resolution
Pulse Width
Accuracy ( 5V logic)
5% to 95%
0.1%
>10
μ
s
±(2.0% rdg+10d)
Frequency range: 5% to 95% ( 40Hz to 20kHz )
The readings of % DUTY CYCLE measurements will show on the sub-
display.
Overload protection: 600V DC or AC rms
Frequency
Range
Resolution
Accuracy
Trigger Level
66Hz
0.01Hz
±(0.1% rdg+5d)
>3.5V
660Hz
6.6kHz
66kHz
660kHz
0.1Hz
1Hz
10Hz
100Hz
±(0.1% rdg+5d)
±(0.1% rdg+5d)
±(0.1% rdg+5d)
±(0.1% rdg+5d)
>3.5V
>3.5V
>3.5V
>3.5V
1MHz
1kHz
±(0.1% rdg+5d)
>3.5V
Minimum Input Range: > 10Hz
Minimum pluse width: > 1μs
Duty cycle limits: > 30% and < 70%
Overload protection: 600VDC or AC rms
