❑ plate for marking slow moving vehicles (being standard tractor equipment), which should be
removed from the tractor and placed at the holder located at the belt gear’s guard.
NOTICE:
Marking slow moving vehicles can be ordered at the mower's manufacturer.
5.5. Moving the mower from transport to working position
WARNING!
Moving the mower to and from operating position from the transport position
should only take place on even and stable ground. Prior to making the moves
make sure whether there are no unauthorized persons exposed to any
hazardous moving parts.
To safely move to the operating position, do the following
❑ open the shut-off valve on the cylinder (Fig. 12a),
❑ lower the mower until the cutter bar is at least 1' 3¾" above the ground (Fig. 13),
❑ make sure there is no person around the danger area,
❑ tension the line, so as the locking pawl can be released (Z) (Fig. 9b) and open tractor's external
hydraulics to set cutter bar by means of hydraulic cylinder into horizontal position,
❑ lower the cutter bar with tractor lever to reach the horizontal position in the slowest way possible,
❑ by means of upper link (S) (Fig. 8) set required mowing height. By extending the link (S) the mowing
height is increased, while shortening it is reduced.
❑ lower mower's front guard.
