The description and the functions of the controls and indications are given below:
LED STATE INDICATION
Blinking Green
Charging is in the state of Bulk or Absorption
depending upon the number of blinks as follows:
For 12 V Battery For 24 V Battery
- 1 Green Blink
> 0.75 V below
Absorption Voltage setting
> 1.5 V below
Absorption voltage setting
- 2 Green Blinks
0.75 V below
Absorption Voltage setting
1.5 V below
Absorption Voltage setting
- 3 Green Blinks
0.5 V below
Absorption Voltage setting
1.0 V below
Absorption Voltage setting
- 4 Green Blinks
0.25 V below
Absorption Voltage setting
0.5 V below
Absorption Voltage setting
- 5 Green Blinks At Absorption Voltage setting At Absorption Voltage setting
Solid Green Charging is in the state of Float
Solid Orange Charging is in the state of Equalization
Solid Red
Charging is in the state of fault: Over current or low DC voltage
or operating temp below 0°C (32°F)
Blinking Red Charging is in the state of fault: Over Temperature
BUTTONS ACTION
Display
Reset Amp-Hours
Push to change the display as in Fig. 5.3.
Push and hold to reset Amp-Hours.
Equalization
Start/Stop
When DIP Switch 5 is set at OFF, hold Restart/Stop Equalization for 5 sec
to manually start equalization. Press it for 2 sec to stop equalization.
