ConstruCtion, layout & Controls
LCD Display
The LCD Display is a 2 Line, 16 character display with backlighting. The Push Switch
marked “PUSH Select Display” and “HOLD – Reset Amp Hours” is used to manipulate
the LCD functions. Every time the Push Switch is pressed momentarily, the screen
display scrolls. The scrolling sequence is shown in Fig. 5.3. Please note that the 7 screens
are sequential & are displayed in a continuous loop: 1 - 2 - 3 - 4 - 5 - 6 - 7 - 1 - 2 - 3 and so on.
Amp Watts BatV
0.0 0.0 12.0
Amp-Hours
0 Ah
Total Amp-Hours
0 Ah
Mode: Charger
State: Bulk
Bulk Float
14.0V 13.4V
EQU EQU-T CYCLE
14.2V 1hr 28day
Heatsink BTS
25
o
C 25
o
C
PUSH: Display Select
PUSH: Display Select
PUSH: Display Select
PUSH: Display Select
PUSH: Display Select
PUSH: Display Select
PUSH: Display Select
LED Display Screens
Screen 1
Screen 2
Screen 3
Screen 4
Screen 5
Screen 6
Screen 7
Fig. 5.3. LCD Display Flow
