Samlexpower SeC-1215UL - SEC-1230 UL Specifications

20 | SAMLEX AMERICA INC.
MODEL NO. SEC-1230UL
INPUT
NOMINAL INPUT VOLTAGE AND FREQUENCY
120 VAC, 50/60 Hz (Default)
230 VAC, 50/60Hz (Internal jumper setting)
AC INPUT CONNECTION
Attached Power Cord:
• 6 ft length
• 3 x 18AWG wire size
• NEMA5-15P Plug
OUTPUT
CHARGING CURRENT 30A
CHARGING STAGES
3 Stages (DIP Switch setting - Default):
• Bulk, Absorption and Float
2 Stages (DIP Switch setting):
• Bulk and Float
CHARGING VOLTAGES
Absorption:
• 14.4 VDC (Default)
• 14.0 VDC (DIP Switch setting)
• Disable (DIP Switch setting)
Float: 13.5 VDC
NO. OF CHARGING BANKS 3
OUTPUT CONNECTIONS
Tubular Hole with Set Screw
Hole Diameter: 4.8 mm / 0.19 in
MONITORING
LED DISPLAY Red LED: Output is available
ANALOGUE METER Ammeter: 0 to 30A
COOLING
TYPE OF COOLING
Temperature controlled fan:
• On when power transformer temperature
rises to 60°C / 140°F
• Off when cools down to 50°C / 122°F
PROTECTIONS
OUTPUT SHORT CIRCUIT No output voltage. Auto reset on removal of short
INPUT OVERLOAD 8A input side fuse will blow (120 VAC input)
OUTPUT OVERLOAD Electronic current limit at 30A
REVERSE POLARITY ON OUTPUT SIDE 2 x 20A output side fuse will blow
OVER TEMPERATURE SHUT DOWN Power transformer temperature rises to 105°C / 221°F
FUSES
INTERNAL AC INPUT SIDE FUSE
(120 VAC OPERATION)
8A, 250V; Size 5mm x 20mm; Time Delay Type
Mfr.: Littelfuse 0218008 or equivalent
INTERNAL AC INPUT SIDE FUSE
(230 VAC OPERATION)
4A, 250V; Size 5mm x 20mm; Time Delay Type
Mfr.: Littelfuse 0218004 or equivalent
INTERNAL DC OUTPUT SIDE FUSE
2 x (32V, 20A); Automotive Blade Type; Fast Acting
Mfr.: Littelfuse 0287020 or equivalent
ENVIRONMENT
OPERATING TEMPERATURE RANGE -20°C to +40°C / -4°F to +104°F
STORAGE TEMPERATURE -30°C to +70°C / -22°F to +158°F
RELATIVE HUMIDITY Up to 90%, non condensing
OPERATING CONDITIONS Indoor, ventilated, cool and dust free
COMPLIANCE
SAFETY
Intertek-ETL Listed as follows:
• Conforms to ANSI/UL Standard 1564
• Certied to CAN/CSA STD. C22.2 No. 107.2
EMI FCC Part 15(B), Class B
DIMENSIONS
L x W x H 280 x 214 x 83 mm / 11.0 x 8.4 x 3.3 in
WEIGHT 2.9 Kg / 6.4 lbs
SECTION 7 | Specications
NOTES: 1. DC voltages are based on battery temperature of 86° F / 26.7°C
2. Specications are subject to change without notice
