SECTION 2 | Layout
2.1 SEC-1215UL
205 4.54.5
30140
218 83
30
214
DIP Switches S1, S2
Common Negative Output Terminal
Isolated Positive Bank Terminals
12V - 15A
Automatic
Battery
Charger
Model
SEC-1215UL
- + + +
1
2
4
3
5 6 7 8
1
2
3
4
5
6 7 8
LEGEND:
Ammeter
Red LED for ON status
AC input power cord
with NEMA5-15 plug
Tubular hole with set screw
• Hole diameter: 4 mm / 0.16”
}
Fig 2.1 Layout - SEC-1215UL
