SECTION 2 | Layout
2.3 SEC-2415UL
1
2
205 4.54.5
214
30190
280
30
9
83
3
5 6 7 8
DIP Switches S1, S2
Common Negative Output Terminal
Isolated Positive Bank Terminals
Cooling Fan
1
2
3
4
5
6 7 8
LEGEND:
Ammeter
Red LED for ON status
AC input power cord
with NEMA5-15 plug
Tubular hole with set screw
• Hole diameter:
4.8 mm / 0.19”
}
24V - 15A
Automatic
Battery
Charger
Model
SEC-2415UL
9
4
2.3 Layout - SEC-2415UL
