Samlexpower SEC-1223 - COMPLIANCE STANDARDS

20 | SAMLEX AMERICA INC.
NOTE: Specications are subject to change without notice.
SEC-1212 SEC-1223
COMPLIANCE
Safety
UL safety listed as “Information Technology Equipment Power Supply” for
USA (UL Standard ANSI/UL-60950-1) and for Canada (CSA Standard CAN/
CSA-C22.2 No. 60950-1)
Electro Magnetic Interfer-
ence EMI – Radiated &
Conducted
FCC Part 15(B), Class B
INPUT / OUTPUT CONNECTIONS
AC Input Connection
• “IEC 60320-C14” Inlet Connector on the unit
• Detachable Power Cord with:
¡ “IEC 60320-C13” Connector on one end
¡ NEMA5-15P Plug on the other end
DC Output Connectors Terminal with Tubular Hole - Diameter 5mm / 0.2” and
set screw (5/64” Hex Socket Head, #10, 24 TPI, 5/16” long)
ENVIRONMENTAL
Operating Temperature
Range
0°C / 32°F to 30°C / 86°F 0°C / 32°F to 40°C / 104°F
DIMENSIONS AND WEIGHT
Dimensions (W x D x H)
185 x 208 x 59.5 mm 185 x 208 x 61 mm
7.28 x 8.19 x 2.34 in 7.28 x 8.19 x 2.40 in
Weight
1.36 kg 1.6 kg
3.0 lb 3.5 lb
SECTION 8 | Specications
