20 | SAMLEX AMERICA INC.
SECTION 8 | Specications
SEC-1235 SEC-1235M
FUSE
Internal AC Side Fuse,
120VAC Input (Preset)
• 5 mm x 20 mm Glass Fuse
• 250V, 8A, Time Delay Type
• Littelfuse - “218008”
Internal AC Side Fuse,
230VAC Input (By inter-
nal jumper setting)
• 5 mm x 20 mm Glass Fuse
• 250V, 4A, Time Delay Type
• Littelfuse - “218004”
COMPLIANCE
Safety
UL safety listed as “Information Technology Equipment Power
Supply” for USA (UL Standard ANSI/UL-60950-1) and for
Canada (CSA Standard CAN/CSA-C22.2 No. 60950-1)
Electro Magnetic Inter-
ference EMI – Radiated &
Conducted
FCC Part 15(B), Class B
INPUT / OUTPUT CONNECTIONS
AC Input Connection
• “IEC 320-C14” Inlet Connector on the unit
• Detachable Power Cord with:

“IEC 320-C13” Connector on one end

NEMA5-15P Plug on the other end
DC Output Connectors Terminal with Tubular Hole - Diameter 5mm / 0.2” and set screw
(5/64” Hex Socket Head, #10, 24 TPI, 5/16” long)
ENVIRONMENTAL
Operating Temperature
Range
0°C / 32°F to 40°C / 104°F
DIMENSIONS AND WEIGHT
Dimensions (W x D x H)
185 x 208 x 61 mm 185 x 212 x 61 mm
7.28 x 8.19 x 2.40 in 7.28 x 8.35 x 2.40 in
Weight
1.54 kg
3.4 lb
