2 Product Specifications
2-1 Specifications
LCD Panel
TFT-LCD panel, RGB vertical stripe, normally black transmissive, TFT-LCD panel, RGB vertical stripe, normally black transmissive,
17-Inch viewable, 0.264 (H) x 0.264 (V) mm pixel pitch 19-Inch viewable, 0.298 (H) x 0.298(V) mm pixel pitch
Scanning Frequency Horizontal : 31 kHz ~ 81 kHz (Automatic) Horizontal : 31 kHz ~ 81 kHz (Automatic)
Vertical : 56 Hz ~ 75 Hz Vertical : 56 Hz ~ 85 Hz
Display Colors 16.2 Million colors 16.7 Million colors
Maximum Resolution Horizontal : 1280 Pixels
Vertical : 1024 Pixels
Input Video Signal Analog, 0.714 Vp-p ± 5% positive at 75 Ω,
internally terminated
Input Sync Signal Type : Separate H/V sync, Composite H/V
Level : TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V), Sync-on-Green (≤ –0.25 V)
Maximum Pixel Clock rate 135 MHz
Active Display
Horizontal/Vertical 338 ± 3 mm / 270 ± 3 mm 376.32 ± 3 mm / 301.056 ± 3 mm
AC power voltage & Frequency AC 90 ~ 264 Volts, 60/50 Hz ± 3 Hz
Power Consumption 42 W (max), 40W (normal) 42 W (max), 40W (normal)
Dimensions
Set (W x D x H)
14.5 x 15.5 x 7.0 Inches (368.2 x 394.3 x 177.0mm) With stand 16.4 x 16.2 x 8.1 Inches (416.3 x 411.7 x 207.0 mm) With stand
14.5 x 12.2 x 2.3 Inches (368.2x 310.1x 58.8 mm) Without stand 16.4 x 13.5 x 2.3 Inches (416.3 x 342.0 x 57.9 mm) Without stand
Package
17.9 x 7.7 x 19.1 Inches (454x 195 x 483 mm) 20.1 x 7.7 x 20.0 Inches (510x 195 x 507 mm)
Weight (Set/Package)
Environmental Considerations Operating Temperature : 50°F ~ 104°F (10°C ~ 40°C)
Operating Humidity : 10 % ~ 80 %
Storage Temperature : -13°F ~ 113°F (-25°C ~ 45°C)
Storage Humidity : 5 % ~ 95 %
• NB17A*/NB19A* complies with SWEDAC (TCO 99) recommendations for reduced electromagnetic fields.
• Designs and specifications are subject to change without prior notice.
Description
NB17A* NB19A*
4.7 kg (10.4 lbs) / 6.0 kg (13.2 lbs) 5.95 kg (13.1 lbs) / 7.8 kg (17.2 lbs)
NB17A*/NB19A* 2-1
