Pivot Stand
(When pivoting the monitor, rotation angle is displayed on screen of the monitor.)
0° 90° 180°
Caution :
When pivoting the monitor, the corner of the monitor may reach to the floor. Tilt the
monitor backward more than 45 degrees and then pivot it. Failure to do so may damage
the monitor.
Attaching a Base
This monitor accepts a 75mm x 75mm VESA-compliant mounting interface pad.
VESA Stand
VESA Mounting Bracket
Fold the monitor stand. Turn it so that the side to which the cable is connected faces down. Attach
the VESA Mounting Bracket to the bottom side of the stand. Align the holes of the bracket with
those in the VESA stand, and fasten it tightly in place with four screws.
