General
General
Model Name SyncMaster 193P plus
LCD Panel
Size 19" Diagonal
Display area 376.32 (H) x 301.056 (V)
Pixel Pitch 0.294mm (H) x 0.294mm (V)
Type a-si TFT active matrix
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 56 ~ 75 Hz
Display Color
16.7M Colors
Resolution
Optimum resolution 1280 x 1024@60 Hz
Maximum resolution 1280 x 1024@75 Hz
Input Signal, Terminated
RGB Analog , DVI Compliant Digital RGB.
Composite H/V Sync,SOG, 0.7Vp-p Positive at 75 ohms
Separate H/V sync,TTL level positive or negative
Maximum Pixel Clock
140 MHz
Power Supply
AC 100 ~ 240 VAC ±10%, 60/50 Hz ± 3Hz
Signal Cable
15pin-to-15pin D-Sub cable, detachable
DVI-D to DVI-D cable (option), detachable
Power Consumption
SyncMaster 193P plus
