Samsung 203B - SyncMaster - 20" LCD Monitor

11 Disassembly and Reassembly
11-3
7. Remove 4 hexa screws from PBA board which
is connected PCB bracket.
8. Remove 4 screws from PBA board and pull up
the PBA from the bracket as picture.
9. Totally disassembled PBA board.
Description Picture Description
11-2 Reassembly
Reassembly procedures are in the reverse order of disassembly procedures.
