Samsung 6001 - Page 2

I I I
° Before connecting your device to the TV, please back up your
files to prevent them from damage or loss of data. SAMSUNG is
not responsible for any data file damage or data loss.
° A USB device that requires high power (more than 0.5A) may not
be supported.
° Do not disconnect the USB device while it is loading.
° The higher the resolution of the image, the longer it takes to
display on the screen.
° If a file is corrupted or the TV does not support the file type, the
"Not Supported File Format" message appears.
° The TV cannot play MP3 files with DRM that have been
downloaded from a for-pay site. Digital Rights Management
(DRM) is a technology that supports the creation, distribution,
and management of digital content in an integrated and
comprehensive way, including protecting the rights and interests
of content providers, preventing illegal copying of contents, and
managing billing and settlements.
° PTP devices are not supported.
° If an over-power warning message is displayed while you are
connecting or using a USB device, the device may not be
recognized or may malfunction.
° If the TV has no input during the time period set in Auto
Protection Time, the Screensaver will run.
° The power-saving mode of some external hard disk drives may
be released automatically when your connect them to the TV.
° If you use a USB extension cable, the TV may not recognize the
USB device or may not be able to read the files on the device.
° If a USB device connected to the TV is not recognized, the list of
files on the device is corrupted, or a file in the list is not played,
connect the USB device to a PC, format the device, and check
the connection.
° If a file you deleted from the PC is ,still found when you run Media
Play, use the "Empty the Recycle Bin" function on the PC to
permanently delete the file.
° Photos only supports the sequential jpeg format.
° The Videos option does not support the scene search and
thumbnail functions.
° If the number of files and folders saved on a USB storage device is
over approximately 4000, the files and folders may not appear and
some folders may not open.
° The maximum displayed number of files, including sub folders, in
one folder of USB storage device is 2000.
° The media may not be playing smoothly when using the device
lower than USB 2.0.
Videos
1. In the Media Play menu, press the _ or !_ button to select
Videos, and then press the ENTER_ button.
2. Press the 4/_/A/T buttons to select a video in the file list.
3. Press the ENTER _ button or [_ (Play) button.
The file name is displayed on the top of the screen with the
playing time.
If video time information is unknown, playing time and the
progress bar are not displayed.
During video playback, you can search using the -ql and
_. buttons.
'_' In this mode, you can play movie clips contained in a game,
but you cannot play the game itself.
-9-
o Supported Subtitle Formats
External
MPEG4 timed text
SAMI
SubRip
SubViewer
Micro DVD
SubStationAlpha
AdvancedSubStationAlpha
Internal
Xsub
SubStationAlpha
AdvancedSubStationAlpha
SubRip
MPEG4 Timedtext
o Supported Video Formats
ii¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i¸i!ii#iii_i!i_i_!_i!iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiill
ttxt
sm_
srt
sub
sub or txt
ssa
ass
iiiiiiiii!i!!!!!i!iiiiiii@_ii_:J_!_iiiiiiiiiii!i!i!iiiii!iiiii!iii
AVI
MKV
MKV
MKV
MP4
Picture Format
Text Format
Text Format
Text Format
Text Format
DivX
3 11/4.x/5 1 1920x1080 6-_30 80Mbps
/60
*rap4 MP4 H264 1920x1080 6-_30 80Mbps
AVC 1920x1080 6-_30 80Mbps
MJPEG 640x480 6-_30 10Mbps
DivX
3 11/4.x/5 1 1920x1080 6-30 80Mbps
/60
*avi AVI, MPEG4 SP
1920x1080 6-30 80Mbps
*mkv MKV /ASP
H264 1920x1080 6-_30 80Mbps
MJPEG 640x480 6-_30 10Mbps
DivX 3 11
/ 4x/5,1 1920x1080 6-_30 80Mbps
/60
ASF
MPEG4 SP
1920x1080 6-_30 80Mbps
/ ASP
H264 1920x1080 6-_30 80Mbps
*ts MPEG2 1920x1080 6-_30 80Mbps
TS H 264 BP
1920x1080 6-30 80Mbps
*m2ts / MP / HP
MPEG1 1920x1080 24/25/30 80Mbps
*dat
MPEG2 1920x1080 24/25/30 30Mbps
PS
H 264 BP
*rob / MP / HP 1920x1080 6-_30 80Mbps
MPEG4 SP
1920x1080 6-_30 80Mbps
*3gp 3GPP /ASP
H264 1920x1080 6-_30 80Mbps
H264 1920x1080 6-_30 30Mbps
*fly flash
*swf formats Sorenson
1920x1080 6-_30 80Mbps
H2e3
MP3 /
ADPCM /
AAC
MP3 /
AC3 /
LPCM /
ADPCM
/ DTS
Core
MP3 /
AC3 /
LPCM /
ADPCM
/ WMA
/ WMA
Pro
AC3 /
AAC /
MP3 /
DD+ /
HE AAC
AC3 /
MPEG /
LPCM /
AAC
MP3
MP3
Other Restrictions Photos
,_Video content will not play, or not play correctly, if ttlere is an error
in the content or the container.
,_Sound or video may not work ifthe contents have a standard
bit rate/frame rate above the compatible Frame/sec listed inthe
Supported Video Formats table.
,_If the Index Table erroneous, the Seek (Jump) function is not
supported.
,_The menu may take longer to appear if the video's bit rate
exceeds 10Mbps.
,_Video content can not be played if there are many contents in 1. In the Media Play menu, press the 4 or _* button to select
one file. Photos, then press the ENTER _ button.
2. Press the _I/_/A/T buttons to select a photoin the file list.
Supports up to H.264, Level 4.1
H.264 FMO / ASO / RS, VC1 SP / MP / AP L4 and AVCHD are
not supported.
MPEG4 SP, ASP :
- Below 1280 x 720:60 frame max
- Above 1280 x 720:30 frame max
H.263 is not supported.
GMC is not support.
Supports up to WMA7, 8, 9 STD, 9 PRO, 10 PRO
WMA 9 PRO and WMA 10 PRO support 5.1 channel. (LBR
mode of WMA Pro is not supported)
WMA Lossless is not supported.
3. Press the ENTER _ button or [_ (Play) button.
'_' NOTE
• While a photo list is displayed, press the _ (Play)/ ENTERF4 J
button on the remote control to start a slide show.
" All files in the file list section will be displayed in the slide show.
" During the slide show, files are displayed in order.
" During the slide show, you can adjust the slide show speed
using (_) (REW) or (_) (FF) button.
" You can move to other files using _1 or I_ button.
_' Media Play can play Music files automatically during a Slide
Show if Background Music is set to On.
'_' You cannot change the Mode in Background Music until the
Background Music file has finished loading.
o Supported Photo Formats
Music
1. In the Media Play menu, press the _1or !_ button to select
Music, and then press the ENTER_ button.
2. Press the 4/I_/A/T buttons to select the desired Music in the
file list.
3. Press the ENTER _ button or _ (Play) button.
'_ During music playback, you can search using the ,_ and
!_ button.
_' [_ (REW) and _ (FF) buttons do not function during
play.
_' Media Play only displays files with MP3 and PCM file
extension. Other file extensions are not displayed, even if they
are saved on the same USB device.
_' If the sound is abnormal when playing MP3 files, adiust the
Equalizer in the Sound menu. (An over-modulated MP3 file
may cause a sound problem.)
Other Restrictions
" CMYK, YCOK Color space JPEG are not supported.
Playing Multiple Files
[] Playing selected video/music/photo files
1. On the File List screen, highlight a file, and then press the Yellow
button on your remote.
2. Repeat Step 1 to select multiple files.
'_' NOTE
° A _ mark appears to the left of the selected files.
" To cancel a selection, press the Yellow button again.
" To deselect all selected files, press the TOOLS button, select
Deselect All, and then the ENTER _4 _button.
3. Press the TOOLS button, select Play Selected Contents, and
then press the ENTER _ button.
[] Playing a video/music/photo folder
1. With the folders on your USB device displayed, use the
_/1_/_/_ buttons to highlight a folder.
2. Press the TOOLS button, select Play Folder, and then press the
ENTER _ button.
-10-
Media Play =Additional Functions
[] Videos/Music/Photos Play Option menus
When playing a file, press the TOOLS button.
Repeat Mode
Picture Size
Picture Mode
Auto Motion
Plus
Sound Mode
Subtitle
Setting
Audio Format
Audio
Language
Stop Slide
Show /
Start Slide
Show
Slide Show
Speed
Background
Music
Zoom
Rotate
Information
_ra
You can select another video file
to pby directly. "/
You can play movie and music
files repeatedly. "/
You can adjust the picture size to
your preference. "/
You can adjust the picture setting. ,,/
You can enhance motion in fast
moving scenes. "/
You can adjust the sound setting. ,,/
You can play the video with
Subtitles. This function only works
if the subtitles have the same file "/
name as the video.
You can select the digital audio
output format. "/
You can change the audio
language if the video has more ,,/
than one language.
You can start or stop a Slide
Show.
You can select the slide show
speed during the slide show.
You can set and select
background music when
watching a Slide Show.
You can zoom into images in full
screen mode.
You can rotate images in full
screen mode.
You can see detailed information
about the played file. "/
-,Z
,,4
-,Z ,,4
,,4
,,4
,,4
,,4
,,4
,,Z ,,4
Settings
Using the Setup Menu
[] DivX® Video On Demand : Shows the registration code
authorized for the TV. If you connect to the DNX web site and
register with the 10-digit registration code, you can download
the VOD activation file. Once you play it using Media Play, the
registration is completed.
'_' For more information on DivX® VOD, visit "http://vod.divx.
corn".
[] Information: Select to vies! information about the connected
USB device.
NOTE
" Standard dimensions for wall mount kits are shown in the table
below.
" When purchasing our wall mount kit, a detailed installation
manual and all parts necessary for assembly are provided.
" Do not use screws that do not comply with the VESA standard
screw specifications.
" Do not use screws that are longer than the standard dimension
or do not comply with the VESA standard screw specifications.
Screws that are too long may cause damage to the inside of the
TV set.
" For wall mounts that do not comply with the VESA standard
screw specifications, the length of the screws may differ
depending on the wall mount specifications.
" Do not fasten the screws too firmly. This may damage the
product or cause the product to fall, leading to personal injury.
Samsung is not liable for these kinds of accidents.
" Samsung is not liable for product damage or personal injury
when a nomVESA or non-specified wall mount is used or the
consumer fails to follow the product installation instructions.
" Do not mount the TV at more than a 15 degree tilt.
" Always have two people mount the TV on a wall.
19_22
26
LED-TV
32,40
75 X 75
M4
100 X 100
4
200 X 200 M6
46_60 400 X 400 M8
Do not install your Wall Mount Kit whib
TV is turned It result in
your
on.
may
personal injury due to electric shock.
Securing the "iV to the Wall
Caution: Pulling, pushing, or Climbing onto _he TV may Cause
the TV to fall. In particular, ensure that Your children do not
hang over or destabilize the TV; doing so may cause the TV
to tip over, resulting in serious injuries or death. Follow all
safety precautions provided on the included Safety Flyer. For
added stability, install the anti-fall device for safety purposes,
as follows.
To prevent the IV from failing
'_, Since the necessary brackets, screws, and string or cable are
not supplied, please purchase these separately.
1. Insert the screws into the wall brackets and firmly fasten them to
the wall. Make sure the screws are firmly fixed to the wall.
'_' We strongly recommend you drive the screws into a stud.
Installing the Wall Mount Kit
The wall mount kit (sold separately) allows you to mount the TV on
the wall.
For detailed information about installing the wall mount, see
the instructions provided with the wall mount items. Contact a
technician for assistance when installing the wall mount bracket.
Samsung Electronics is not responsible for any damage to the
product or injury to yourself or others if you elect to install the wall
mount on your own.
Wall Mount Kit Specifications 6/ESA)
'_, The wall mount kit is not supplied, but sold separately.
Install your wall mount on a solid wall perpendicular to the floor.
When attaching to other building materials, please contact your
nearest dealer. If you install the TV on a ceiling or slanted wall, it
may fall and result in severe personal injury.
2. Using screws, insert the screws through the TV brackets, and
then fasten the screws to the top VESA screw holes on the back
of the T_
3. Connect the brackets on the TV and the brackets on the wall
with a strong string or cable, and then tie the string or cable
tightly to the brackets.
_' Verify all connections are properly secured. Periodically check
the connections for any sign of fatigue or failure. If you have
any doubt about the security of your connections, contact a
professional installer.
'_ Install the TV close to the wall so that it does not fall.
'_' Connect the string or cable so that the brackets on the wall
are at the same height or lower than the brackets on the TV.
Untie the string or cable before moving the TV.
'_' To purcase a TV Holder kit, contact Samsung customer care.
-11-
_ton Lock
The Kensington Lock is not supplied by Samsung. It is a device
used to physically fix the system when using it in a public place.
Refer to the manual provided with the Kensington Lock for additional
information on proper use.
'_' Please find a "i_" icon on the rear of the TV. The Kensington
slot is beside the "i_" icon.
'_' The position and color may differ depending on the model.
Dis la IVlodes HDMI/DVI In ut
Optimal resolution is 1920 x 1080@60Hz.
IBM
MAC
VESA DMT
640 x 350 31 469 70086 25176
720 x 400 31 469 70087 28322
640 x 480 35000 66667 30240 /
832 x 624 49726 74551 57284 /
1152 x 870 68681 75062 100000 /
640x 480 31469 59940 26176 /
640 x 480 37861 72809 31600 /
640 x 480 37500 75000 31600 /
800 x 600 37879 60317 40000 +/+
800 x 600 48077 72188 60000 +/+
800 x 600 46875 75000 49500 +/+
1024 x 768 48363 60004 65 000 /
1024 x 768 56476 70069 75000 /
1024 x 768 60023 76029 78 750 +/+
1152 x 864 67500 76000 108000 +/+
1280 x 720 45000 60000 74250 +/+
1280 x 800 49702 69810 83500 /+
1280x 1024 63981 60020 108000 +/+
1280 x 1024 79976 76 025 135000
1366 x 768 47712 69790 85500
1440 x 900 55935 69 887 106500 /+
1600x 900RB 60000 60000 108000 +/+
1680 x 1050 65290 69 954 146 250 /+
1920 x 1080 67600 60000 148500 +/+
Troubleshooting
If the TV seems to have a problem, first review ttqis list of possible problems and solution. If none of these troubleshooting tips apply, visit
samsung.com, ttqen click on Support, or call Samsung customer service at 1-800-SAMSUNG.
Flickering and Dimming
Component Connections /
Screen Color
If your Samsung Television is flickering or dimming sporadically, you may need to disable some of its energy efficient
features like the Energy Saving feature. Follow the steps below with your remote to turn these features off or on.
Energy saving : Menu _ Setup _ Eco Solution _ Energy Saving _Select Settings
If you find that the color on your Samsung television's screen is not correct or black and white, first run a Self
Diagnosis Test on the TV to make sure there are no device issues.
Self Diagnosis : User Menu _ Support _ Self Diagnosis _ Picture Test
_. If the test is ok, try making sure ;
_. Your connections are all consistent. For example, if you've used the AV In jack on your TV, make sure you have
used the AV Out jack on your video source.
_. Try making sure you have connected to the correct jacks. For example, if you use the Component jacks, labeled
Pb, Pr, and Y, to connect your TV and video source, make sure you have connected the blue Pb jack on the
video source to the blue Pb jack on the TV, the red Pr jack on the source to the red Pr jack on the TV.
Screen Brightness If you find that the colors on your Samsung TV are correct but just a little too dark or bright, there are some settings
you should check before calling for a repair.
_. Backlight, Contrast, Brightness, Sharpness, Color, Tint and so on. Go to "Picture" in the Menu, and then try
adjusting these options.
Unwanted Powering off
Trouble Powering On
If your Samsung TV appears to turn off by itself,there may be an bsue with either your Timer settings or your Eco
friendly No Signal Power Off feature.
First make sure the Sleep Timer is not accidentally set. The Sleep Timer lets you fall asleep with the TV still on
knowing that it will turn off after a certain period of time and not waste energy.
_. Sleep Timer : User Menu _ Setup _ Time _ Sleep Timer
If the Sleep Timer is not activated, you may have engaged the No Signal Power Off or Auto Power Off feature.
_. No Signal Power Off : User Menu _ Setup _ Eco Solution _ No Signal Power
_, Auto Power Off : User Menu _ Setup _ Eco Solution _ Auto Power Off
Before you turn the TV on, find the red light on the right or left bottom of your TV. Press the power on button
on the TV or remote and the light should blink about 5 times before the TV turns on.
If you find that you are having trouble powering on your Samsung tebvision, there are a number of things to check it
before making a call to the service department.
_. If you happen to be using the TV as a monitor and the stand-by light only blinks for a few seconds when you
press the power button, your PC is in sleep mode. To take your PC out of sleep mode, press a key on your
keyboard or move the mouse. Then try turning your TV on.
If you're sure your power cord, remote control, and PC are functioning properly, you may be having a cable issue. If
you have a cable or satellite box, your TV may appear to be off because the cable or satellite box is not outputting a
signal. To test the signal output of your cable or satellite box, press the guide or info button on the cable or satellite
box remote control. If the screen displays the guide or info data, the problem is caused by the box.
-12-
Stand Assembly * If you have any trouble assembling the stand, refer to "Install the Stand" in the Start Up or Stand Installation Guide.
Cannot find a channel * Re-run Plug & Play or run Auto Program. (go to MENU - Channel - Auto Program)
Po0r Picture First, perform the picture Test and to see ifyour IV is displaying the test image properly.
Go to MENU _Support = Self Diagnosis-. Picture Test
If the test image is properly displayed, the poor picture may be caused by the source or signal.
The TV image does not look as good as If you have an analog cable/satellite box, upgrade to a digital set top box. Use HDMI or Component cables to
it did in the store, deliver HD (high definition) picture quality.
Cabb/Satellite subscribers: Try HD channels from the channel line up.
Air/Cabb Antenna connection: Try HD channels after running Auto Program.
Many HD channels broadcast up scaled SD (Standard Definition) content. The picture quality of up
scaled SD content is low.
Adjust the Cable/Set top box video output resolution to 1080i or 720p.
The picture is distorted: macroblock * Compression of video contents may cause picture distortion, especially on fast moving pictures such as those in
error, small block, dots, pixelization, sports and action movies.
• A weak signal can cause picture distortion. This is not a TV problem.
• Mobile phones used close to the TV (within 3.3ft) may cause noise in the picture on analog and digital channels.
Color is wrong or missing. * If you're using a component connection, make sure the component cables are connected to the correct jacks.
Incorrect or loose connections may cause color problems or a blank screen.
There is poor color or brightness. * Adjust the Picture options in the TV menu. (go to Picture Mode / Color / Brightness / Sharpness)
• Adjust the Energy Saving option in the TV menu. (go to MENU - Setup - Eco Solution - Energy Saving )
Try resetting the picture to the default picture settings. (go to MENU - Picture - Picture Reset)
There is a dotted line on the edge of * If the picture size is set to Screen Fit, change it to 16:9.
the screen. * Change the cable/satellite box resolution.
The picture is black and white. * If you are using an AV composite input, connect the video cable (yellow) to the Green jack of Component Input 1
on the TV.
When changing channels, the picture * If connected to a cable box, please try to reset it. (Reconnect the AC cord and wait until the cable box reboots. It
freezes or is distorted or delayed, may take up to 20 minutes)
Set the output resolution of the cable box to 1080i or 720p.
Sound Problems perform the S0und Test to confirm that YOUr_ audio is properly olaerating,
(go to MENU _ Support : Self Diagnosis - Sound Test)
if the audio is OK, the sound problem may be caused by the source or signal
There is no sound or the sound is too * Check the volume of the device (Cable/Sat Box, DVD, Blu-ray, etc.) connected to your TV.
low at maximum volume.
The picture is good, but there is no * if you are using an external device, check the device's audio output option Ex. you may need to change your cable
sound, box's audio option to HDMI if the box b connected to your TV using an HDMI cable.
Reboot the connected device by reconnecting the device's power cable.
The speakers are making an * Check the cable connections. Make sure a video cable is not connected to an audio input.
inappropriate noise. * For Antenna or Cable connections, check the signal information. A weak signal may cause sound distortion.
Perform the Sound Test as explained above.
No Picturel No Video I
The TV will not turn on. • Make sure the AC power cord is securely plugged into the wall outlet and the TV.
Make sure the wall outlet is working.
Try pressing the POWER button on the TV to make sure the problem is not the remote.
It the IV turns on, reter to 'Remote control does not work' below.
The TV turns off automatically. * Ensure the Sleep Timer is set to Off in the Time menu.
If your PC is connected to the TV, check your PC power settings.
Make sure the AC power cord is plugged securely into the wall outlet and the TV.
When you are watching TV connected to an antenna or cable connection, the TV will turn off after 10 - 15 minutes
if there is no signal.
There is no picture/video. Check the cable connections. (Remove and reconnect all cables connected to the TV and external devices).
Set your external device's (Cable/Sat Box, DVD, Blu-ray etc) video outputs to match the connections to the TV
input. For example, if an external device's output is HDMI, it should be connected to an HDMI input on the TV.
Make sure your connected devices are powered on.
Be sure to select the correct input source by pressing the SOURCE button on the remote control.
Reboot the connected device by reconnecting the device's power cable.
RF (Cable/Antenna) Connection
The TV is not receiving all channels. * Make sure the coaxial cable is connected securely.
Run Auto Program to add available channels to the channel list.
go to MENU - Channel - Auto program then select Auto and make sure the correct Cable TV signal type is set
in the menu. There are 3 options. (STD, HRC and IRC)
Verify the antenna is positioned correctly.
No Caption on digital channels. * Check the Caption Setup menu. Try changing Caption Mode Service 1 to CCl.
Some channels may not have caption data.
The picture is distorted: macroblock, * Compression of video contents may cause picture distortion, especially on fast moving pictures such as those in
error, small block, dots, pixelization, sports and action movies.
A weak signal can cause picture distortion, This is not a TV problem,
Others
Purpb/green rolling borizontal bars and * Remove the left and right audio connections from the set4op-box. If the buzzing stops, this indicates that the set-
buzzing noise from the TV speakers with top-box has a grounding issue. Replace the Component video cables with an HDMI connection.
Component cable connection.
The picture will not display in full screen. * HD channels will have black bars on either side of the screen when displaying up scaled SD (4:3) contents.
Black bars on the top and bottom appear when movies that have aspect ratios different from your TV play on the
TV.
Adjust the picture size option on your external device or change the TV to full screen.
The remote control does not work. * Replace the remote control's batteries. Make sure you insert them with the polarity (+/-) correct.
Clean the transmission window located on the top of the remote control.
Try pointing the remote directly at the TV from 5,_6 feet away.
The cabb/set top box remote control * Program the Cabb/Set top box remote control to operate the TV. Refer to the Cabb/Set top box user manual for
does not turn the TV on or off, or adjust the SAMSUNG TV code.
the volume.
A "Mode Not Supported" message • Check the supported resolution of the TV and adjust the external device's output resolution accordingly. Refer to
appears, resolution settings in this manual.
Caption on the TV menu is greyed out. * You cannot select Caption in the TV menu when watching content from a device connected via HDMI or
Component.
Caption must be activated on the external device.
There is a pbstic smell from the TV. • This smell is normal and will dissipate in a few days.
%/Signal Strength is unavailable in the * This function is only available for digital channels received through an Antenna / RF/Coax connection.
Self Diagnosis Test menu.
TV is tilted to the right or left side. * Remove the stand base from the TV and reassemble it.
The Channel menu is grey out * The Channel menu is only available when you select the TV source.
(unavailable).
Your settings are lost after 30 minutes or * If TV is in the Store Demo mode, it will reset audio and picture settings every 30 minutes, Please change from
every time the TV is turned off. Store Demo mode to Home Use mode using the Plug & Play procedure. Press the SOURCE button to select
TV mode, go to MENU _ Setup _ Plug & Play _ ENTER E:_.
You have intermittent loss of audio or * Check the cable connections and reconnect them.
video. * Loss of audio or video can be caused by using overly rigid or thick cables. Make sure the cables are flexible
enough for long term use. If mounting the TV to the wall, we recommend using cables with 90 degree connectors.
You see small particles when you look * This is part of the product's design and is not a defect.
closely st the edge of the frame of
the TV.
POP (TV's internal banner ad) appears * Select Home Use under Plug & Play mode. For details, refer to Plug & Play (Initial Setup).
on the screen.
'_' This TFT LED panel uses a panel consisting of sub pixels which require sophisticated technology to produce. However, there may
be a few bright or dark pixels on the screen. These pixels will have no impact on the performance of the product.
'_' Watch these troubleshooting on video at www.samsung.com/spsn.
'_' Some functions and pictures shown in this manual are available on specific models only.
'_' You can keep your TV in optimum condition by upgrading it with the latest firmware from the Samsung web site (samsung.com
Support -_ Downloads). To upgrade, download the firmware to your computer, copy the firmware file to a USB memory stick,
insert the USB memory stick into the TV's USB slot, and then select Support > Software Upgrade in the TV's menu.
Storage and Maintenance
'_' If a sticker was attached to the TV screen, some debris can remain after you remove the sticker. Please clean it before watching
the TV.
'_' The exterior and screen of the product can get scratched during cleaning. Be sure to wipe the exterior and screen carefully using
a soft cloth to prevent scratches.
License
D° not spray water directly onto the _r_- tl
product. Any liquid that goes into the
product may Cause a failure, fire, or
electric shock.
Clean the product with a Soft Cloth
dampened with in a small amount of
water. Do not use a flammable liquid
(e.g. benzene, thinners) or a cleaning
agent,
TM
TheaterSound, SRS and the _ symbol are SRS TheaterSound provides the most immersNe
$ I"5
trademarksofSRSLabs,,nc surroondsoondexper,enoefromtheTM'sbo,,t,n
Thea_erSound_ TheaterSound technology is incorporated under speakers, while maintaining steady volume and
license from SRS Labs, Inc. delivering rich bass and clear dialog,
_n _11_[,, DivX Certified® to play DNX® video up to HD 1080p, including premium content.
HD
ABOUT DIVXVIDEO: DNX@ is a digital video format created by DNX, LLC, a subsidiary of Rovi Corporation. This is an official DNX
Certified® device that plays DivX video. Visit divx. corn for more information and software tools to convert your files into DivX videos.
ABOUT DIVXVIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play purchased DNXVideo-on-
Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod. divx.
corn for more information on how to complete your registration. Covered by one or more of the following U.S. patents ; 7,295,673;
7,460,668; 7,515,710; 7,519,274 DNX®, DivX Certified® and associated Iogos are trademarks of Rovi Corporation or its subsidiaries
and are used under license,
[][] DOLBY
OlalTAL PLUS I
_ULSE 1
Manufactured under license from Dolby Laboratories. Dolby and the doubb-D symbol are trademarks of
Dolby Laboratories.
Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535 & other U.S. and
@_ worldwide patents issued & pending. DTS, the Symbol, & DTS and the Symbol together are registered
2.0Channel trademarks & DTS 2.0 Channel is a trademark of DTS, Inc. Product includes software. @ DTS, Inc. All Rights
Reserved.
_ _ _ The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or
[]
registered trademarks of HDMI Licensing LLC in ttqe United States and other countries.
Open Source License Notice
Open Source used in this product can be found on the following webpage. (http://opensoume.samsung.com) Open Source License
Notice is written only English.
To send inquires and requests for questions regarding open soumes, contact Samsung via Email (oss.mquest@samsung.com).
[] This product uses some software programs which are distributed under the Independent JPEG Group.
ICU License - ICU 1.8.1 and later
COPYRIGHT AND PERMISSION NOTICE
Copyright (c) 1995-2008 International Business Machines eorperation and others All rights reserved.
Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software
without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, and/or sellcopies of the Software, and to permit persons to
whom the Software is furnished to do so, provided that the above copyright notice(s) and this permission notice appear in all copies of the Sofb¢,_areand that both the
above copyright notice(s) and this permission notice appear in supperting documentatien.
THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OFANY KIND, EXPRESS OR IMPUED, INCLUDING BUT NOT UMITED TO THE WARRANTIES
OF MERCHANTABILITy, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OF THIRD PARTY RIGHTS. IN NO EVENT SHALL THE COPYRIGHT
HOLDER OR HOLDERS INCLUDED IN THIS NOTICE BE LIABLE FOR ANY CLAIM, OR ANY SPECIAL INDIRECT OR CONSEQUENTIAL DAMAGES, OR ANY
DAMAGES WHATSOEVER RESULTING FROM LOSS OF USE, DATAOR PROFITS,WHETHER IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTIOUS
ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.
Except as contained in this notice, the name of a copyright holder shall not be used in advertising or otherwise to promote the sale, use or other dealings in this Software
without prior written authorization of the copyright holder.
All trademarks and registered trademarks mentioned herein are the property of their respective owners.
Environmental Considerations
_ating Temperature
StorageTemperature
Storage Humidity
50°F to 104°F (10°C to 40°C)
10% to 80%, non-condensing
-4°F to 113°F (-20°C to 45°C )
5% to 95%, non-condensing
1920 x 1080
55" Class 60" Class 65" Class
(Diagonal) (54.6" measured diagonally) (60.0" measured diagonally) (64.5" measured diagonally)
Sound
Output 10W x 2
Dimensions_ _x H x D)
49.2 X 28.9 X 3.7 inches 54.1 X 22.2 X 3.7 inches 58.4 X 34.4 X 3.7 inches
(125g.6 X 735.7 X 94.3 (ram)) (1375.6 X 565.1 X 94.4 ((ram)) (1484.5 X 873.8 X 96.3 (ram))
49.2 X 31.0 X 8.9 inches 54.1 X 33.9 X 12.9 inches 58.4 X 36.4 X 12.9 inches
(1250.6 X 789.2 X 227.6 (ram)) (1375.6 X 862.5 X 329.7 ((ram)) (1484.5 X 926.5 X 329.8 (ram))
Without Stand 38.8 Ibs (t 7.6 kg) 49.8 Ibs (22.6 kg) 63.0 Ibs (28.6 kg)
With Stand 44.7 Ibs (20.3 kg) 59.0 Ibs (26.8 kg) 72.3 Ibs (32.8 kg)
'_, Design and specifications are subject to change without prior notice.
'_, This device is a Class B digital apparatus.
'_, For information about power supply, and more about power consumption, refer to the label attached to the
product.
"_, Typical power consumption is measured according to Energy Star Program requirements for Televisions.
'_, Dispose unwanted electronics through an approved recycler, To find the nearest recycling location, go to our
website: www.samsung,com/recyclingdirect or call, (877) 278-0799.
[] JACK PANEL DETAIL / REAR VIEW
(Unit: inches)
UN55FH6003 16.7 15.7 15.7 6.1 7.5 36.4 12.6
UN60FH6003 19.1 15.7 15.7 8.6 9.2 38.8 14.9
UN65FH6001 21.3 15.7 15.7 10.7 9.5 41.0 17.2
NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the dimensions
prior to performing installation of your TV. Not responsible for typographical or printed errors.
© 2013 Samsung Electronics America, Inc
-13- -14- -15- -16-
[UFH6003-ZA]BN68-05495A-00ENGindd 2 2013-07-29 BI]9:24:44
