5-3
ANNEX
5-2. Board Connection (Main Board)
RS232C
PC (D-SUB/DVI)
Component
(D-sub)
AV(Audio,Video),
PC audio, DVI out,
HDMI
SMPS
Speaker
T-CON
Fan
Fan
BNC Board
