Disassembly and Reassembly

Samsung Electronics 3-71

No Parts Procedure Remark

4 EVAPORATOR

6) Pull up the EVAPORATOR of the opposite

side of the Fan Moter.

7) loosen a hook of the Fan Moter side.

8) Pull up the EVAPORATOR toward to you.
