Disassembly
and Reassembly
Samsung Electronics
3-139
No.
Par
t
s
Procedure
Remark
14
EEV
Valv
e
1)
Remove
the 2 scr
ews
which is fixed
to Service
Val
ve and separate it. (Use
+Scr
ew
Driver)
2)
Separat
e the inlet and outl
et pipes
by
welding torch
