Disassembly and Reassembly
Samsung Electronics 3-19
No Parts Procedure
Remark
7 Heat Exchanger 1) Remove the screw fixed in Heat
Exchanger. (Use +Screw Driver)
2) Separate the indoor unit SENSOR from
the Heat Exchanger.
3) Separate the EEV connector from the
PCB.
4)
Separate the Heat Exchanger from the
indoor unit.
5)
Separate the EXPANSION COIL from the
EEV BODY.
(When servicing the EEV)
To Next Page
