Disassembly and Reassembly
Samsung Electronics 3-37
No. Parts Procedure Remark
2 Control Box
3) Remove a screw which is fixed to the
Indoor Unit upper part.
(Use +Screw Driver)
4) Put finger in the "PULL" marked groove
and then pull up the Cover
5) Put finger in the "PULL" marked groove
and then avoids the hook and it opens the
Control Box Cover
To Next Page
