Samsung AC024BNHDCH - Indoor Unit Disassembly - Top Cover and Display

Disassembly and Reassembly
3-40 Samsung Electronics
No. Parts Procedure
Remark
3 Top Cover &
Drain Pan
7) Remove the screw and separate the
Display Cover.
(Use +Screw Driver)
8) Remove the 2ea of screws.
(Use +Screw Driver)
9) Push the hook and separate the Cover.
10) Remove 8ea of screws.
(Use +Screw Driver)
11) Separate the Indoor Unit upper part
from the Body.
