Disassembly and Reassembly

3-98 Samsung Electronics

No. Parts Procedure Remark

7 Cabinet Front LF

8 Fan 1) Remove the 2 hex nuts like the

picture on the right side.

(Use Hexagon Wrench, Monkey

Spanner, Hexagon Socket)
