Disassembly and Reassembly

3-130 Samsung Electronics

No. Parts Procedure Remark

15 Condenser

Connection Part

Remove 3ea of screws which are fixed

to each side of Condenser Connection

Part and separate it.

(Use + Screw Driver)
