Disassembly and Reassembly
Samsung Electronics 3-35
No. Parts Procedure Remark
1 Panel ▶ Ceiling type Panel
1) Pull up the corner 4 places of Panel and
separate it.
2) Remove 4ea of screws from the corner
of Panel.
(Use +Screw Driver)
3) Pull the hook of Panel and then
separate
the Panel from the Indoor Unit.
1 Panel ▶ Open type Panel
1) Rotate the outside Panel to
counterclockwise direction and then
separate it.
■ 360 CST : AC***BN6DCH
