Samsung AC030KNZDCH/AA Technical Bulletin

7(&+1,&$/%8//(7,1
ZZZ6DPVXQJ+9$&FRP7%

+9$&

MODEL DESCRIPTION Default Product Option Code Cooling Only Product Option Code
AC018JN4DCH/AA 18k Btu/h, 4-Way Cassette 0140EF-1950D8-27343B-370005 0140EF-1900D8-27343B-370005
AC024JN4DCH/AA 24k Btu/h, 4-Way Cassette 0140EF-1950D8-274750-370005 0140EF-1900D8-274750-370005
AC030JN4DCH/AA 30k Btu/h, 4-Way Cassette 0140EF-1950E8-275A64-370045 0140EF-1900E8-275A64-370045
AC036JN4DCH/AA 36k Btu/h, 4-Way Cassette 0140EF-195439-276470-370045 0140EF-190439-276470-370045
AC042JN4DCH/AA 42k Btu/h, 4-Way Cassette 0140EF-19544A-277D8C-370045 0140EF-19044A-277D8C-370045
AC048JN4DCH/AA 48k Btu/h, 4-Way Cassette 0140EF-19545B-278CA0-370045 0140EF-19045B-278CA0-370045
AC018MNHDCH/AA
18k Btu/h, CAC Duct S HSP, (default) 01B0EC-1E5411-27343B-374000 01B0EC-1E0411-27343B-374000
AC024MNHDCH/AA
24k Btu/h, CAC Duct S HSP, (default) 01B0EC-1E5407-274750-374020 01B0EC-1E0407-274750-374020
AC030MNHDCH/AA
30k Btu/h, CAC Duct S HSP, (default) 01B0EC-1E54B8-275A64-376020 01B0EC-1E04B8-275A64-376020
AC036MNHDCH/AA
36k Btu/h, CAC Duct S HSP, (default) 01B0EC-1E5403-276470-376045 01B0EC-1E0403-276470-376045
AC042MNHDCH/AA 42k Btu/h, CAC Duct S HSP, (default) 01B0EC-1E5424-277D8C-377045 01B0EC-1E0424-277D8C-377045
AC048MNHDCH/AA
48k Btu/h, CAC Duct S HSP, (default) 01B0EC-1E5468-278CA0-377045 01B0EC-1E0468-278CA0-377045
AC018JNHDCH/AA 18k Btu/h, CAC Duct, (DEFAULT) 01C0EC-1C8424-27343B-370005 01C0EC-1C0424-27343B-370005
AC024JNHDCH/AA 24k Btu/h, CAC Duct, (DEFAULT) 01C0EC-1C747C-274750-370005 01C0EC-1C047C-274750-370005
AC030JNHDCH/AA 30k Btu/h, CAC Duct, (DEFAULT) 0100EC-1A55D4-275A64-370005 0100EC-1A05D4-275A64-370005
AC036JNHDCH/AA 36kBtu/h, CAC Duct, (DEFAULT) 0100EC-1A5902-276470-370005 0100EC-1A0902-276470-370005
AC042JNHDCH/AA 42k Btu/h, CAC Duct, (DEFAULT) 0100EC-1A194D-277D8C-370005 0100EC-1A094D-277D8C-370005
AC048JNHDCH/AA 48k Btu/h, CAC Duct, (DEFAULT) 0100EC-1A1A81-278CA0-370005 0100EC-1A0
A81-278CA0-370005
AC018KN4DCH/AA 18k Btu/h, 360 Cassette 0100EF-1950D8-27343B-370005 0100EF-1900D8-27343B-370005
AC024KN4DCH/AA 24k Btu/h, 360 Cassette 0100EF-1950D8-274750-370005 0100EF-1900D8-274750-370005
AC030KN4DCH/AA 30k Btu/h, 360 Cassette 0100EF-19541A-275A64-370045 0100EF-19041A-275A64-370045
AC036KN4DCH/AA 36k Btu/h, 360 Cassette 0100EF-19548C-276470-370045 0100EF-19048C-276470-370045
AC042KN4DCH/AA 42k Btu/h, 360 Cassette 0100EF-19549D-277D8C-370045 0100EF-19049D-277D8C-370045
AC048KN4DCH/AA 48k Btu/h, 360 Cassette 0100EF-1954AF-278CA0-380045 0100EF-1904AF-278CA0-380045
AC009KNLDCH/AA 9k Btu/h, CAC Slim Duct, (DEFAULT) 01C06C-1C7933-271A21-370000 01C06C-1C0933-271A21-370000
AC012KNLDCH/AA 12k Btu/h, CAC Slim Duct, (DEFAULT) 01C06C-1C7968-272328-370000 01C06C-1C0968-272328-370000
AC018KNLDCH/AA 18kBtu/h, CAC Slim Duct, (DEFAULT) 01C06C-1C7944-27343C-370000 01C06C-1C0944-27343C-370000
AC018KNZDCH/AA 18k Btu/h, Multi-position AHU 01E06C-105020-27343B-370005 01E06C-100020-27343B-370005
AC024KNZDCH/AA 24k Btu/h, Multi-position AHU 01E06C-105020-274750-370005 01E06C-100020-274750-370005
AC030KNZDCH/AA 30k Btu/h, Multi-position AHU 01E06C-105020-275A64-370005 01E06C-100020-275A64-370005
AC036KNZDCH/AA 36k Btu/h, Multi-position AHU 01E06C-105020-275A64-370005 01E06C-100020-275A64-370005
AC042KNZDCH/AA 42k Btu/h, Multi-position AHU 01E06C-105020-277D8C-370005 01E06C-100020-277D8C-370005
AC048KNZDCH/AA 48k Btu/h, Multi-position AHU 01E06C-105020-278CA0-370005 01E06C-100020-278CA0-370005
AC054KNZDCH/AA 54k Btu/h, Multi-position AHU 01E06C-105020-27A0B4-370005 01E06C-10
0020-27A0B4-370005
&$&3URGXFW2SWLRQ&RGHV
)RUDGGLWLRQDOSURGXFWRSWLRQFRGHVWRDGMXVW(63([WHUQDO6WDWLF3UHVVXUHVHWWLQJVIRUGXFWHGXQLWVSOHDVHUHIHU
WRWKHDSSURSULDWHLQVWDOODWLRQPDQXDO
1RWH6HJPHQWVKRXOGEHFKDQJHGWRWRFRQILJXUHDXQLWWR&RROLQJ2QO\
0HWKRG2: Setting the controller as "Cooling Only" in the Service Mode of a Wired Controller
All wired controllers can be configured to skip heating mode as a selectable option by the occupant. It is recommended to use
method 1 of this document. If only the controller is setup to skip heating mode, the mode can still be changed to heating
operation via wireless controller or central controls.
To configure the wired controller as cooling only (skip heat mode), refer to the installation manual of the applicable wired
controller.
