Samsung AC052MN4DKH - Setting an Indoor Unit Installation Option (Suitable for the Condition of each Installation Location)

Troubleshooting
4-6 Samsung Electronics
1. Check whether power is supplied or not.
- When the indoor unit is not plugged in, there should be additional pow er supply in the indoor unit.
2. The panel(display ) should be connected to an indoor unit to receive option.
3.
Set the installation option according to the installation condition of an air conditioner.
- The default setting of an indoor unit installation option is 02000-100000-200000-300000.
- Individual control of a remot e controller(SEG20) is the function that controls an
indoor unit individually when there is more
than one indoor unit.
4. Set the indoor unit option by wireless remote controller.
▶
1WAY/2WAY/4WAY MODEL : Drain pump(SEG8) will be set to 'USE + 3minute delay' even if the drain pump is set to 0.
▶
1 WAY/2WAY/4WAY, DUCT MODEL : Number of hours using lter(SEG18) will be set to '1000hour' even if the SEG18 is set to
exept for 2 or 6.
▶
If you input a number other than 0~4 of the individual control of the indoor unit(SEG20), the indoor is set as indoor 1.
▶
4WAY MODEL : Even when the value of Heating setting compensation(SEG21) is set to '0', it wil be recognized as '5°C'.
4-1-4 Setting an indoor unit installation option (Suitable for the condition of each installation location)
SEG1 SEG2 SEG3 SEG4 SEG5 SEG6
0 2 RESERVED
Exterior temperature
sensor
Central controlFAN RPM
SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
1 Drain pump RESERVEDRESERVED
Indoor unit at
heating stop
RESERVED
SEG13 SEG14 SEG15 SEG16 SEG17 SEG18
2External control
External control
output
S-Plasma ion Buzzer
Numb
er of hours
using lter
SEG19 SEG20 SEG21 SEG22 SEG23 SEG24
3
Individual control of
a r emote controller
Heating setting
compensation
RESERVEDRESERVEDRESERVED
