Product Specifications
Samsung Electronics 2-5
Indoor Unit(cont.)
Q 4WAY casette (Small)
Model
4WAY casette - Small
AM009FN4DCH/AA AM012FN4DCH/AA AM018FN4DCH/AA AM024FN4DCH/AA
Power Supply ø, #, V, Hz 1,2,208-230,60 1,2,208-230,60 1,2,208-230,60 1,2,208-230,60
Mode
-
HP/HR HP/HR HP/HR HP/HR
Performance
Capacity
(Nominal)
Cooling 2)
kW
- ---
Btu/h 9,000 12,000 18,000 24,000
Heating 2)
kW
- ---
Btu/h 10,000 13,500 20,000 27,000
Condensate
(with high fan
speed)
Liter/h
- ---
Power
Power Input
(Nominal)
Cooling 1) W
32 32 32 40
Heating 2) - 32 32 32 40
Current Input
(Nominal)
Cooling 1) A
0.25 0.25 0.25 0.3
Heating 2) - 0.25 0.25 0.25 0.3
Fan
Type -
Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Motor
Model -
FMC6531SSH FMC6531SSH FMC6531SSH FMC6531SSH
Type - BLDC BLDC BLDC BLDC
Output x n W 65 x 1 65 x 1 65 x 1 65 x 1
Air Flow Rate H/M/L CMM 15.50 / 14.00 / 12.00 15.50 / 14.00 / 12.00 15.50 / 14.00 / 12.00 17.50 / 16.00 / 14.00
External Pressure
Min / Std / Max Pa
- ---
-WG - ---
Sound
Sound Pressure High / Mid / Low dBA
----
Sound Power High / Mid / Low - ---
Refrigerant
Type -
R-410A R-410A R-410A R-410A
Control Method - EEV INCLUDED EEV INCLUDED EEV INCLUDED EEV INCLUDED
Temperature Control - Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety devices - Fuse Fuse Fuse Fuse
Piping
Connections
Liquid Pipe (Flare)
ø,mm
6.35 6.35 6.35 9.52
ø, inch 1/4 1/4 1/4 3/8
Gas Pipe (Flare)
ø,mm
12.7 12.7 12.7 15.88
ø, inch 1/2 1/2 1/2 5/8
Drain Pipe (Quick lock) ø,mm VP25 (OD32,ID25) VP25 (OD32,ID25) VP25 (OD32,ID25) VP25 (OD32,ID25)
Dimensions
Net Weight
kg
15.00 15.00 15.00 15.00
lbs 33.07 33.07 33.07 33.07
Shipping Weight
kg
18.50 18.50 18.50 18.50
lbs 40.79 40.79 40.79 40.79
Net Dimensions (W×H×D)
mm
840 x 204 x 840 840 x 204 x 840 840 x 204 x 840 840 x 204 x 840
inch 33.07 x 8.03 x 33.07 33.07 x 8.03 x 33.07 33.07 x 8.03 x 33.07 33.07 x 8.03 x 33.07
Shipping Dimensions (W×H×D)
mm
898 x 275 x 898 898 x 275 x 898 898 x 275 x 898 898 x 275 x 898
inch 35.35 x 10.83 x 35.35 35.35 x 10.83 x 35.35 35.35 x 10.83 x 35.35 35.35 x 10.83 x 35.35
Panel Size
Panel model -
PC4NUSKFN PC4NUSKFN PC4NUSKFN PC4NUSKFN
Panel Net Weight
kg
5.80 5.80 5.80 5.80
lbs 12.79 12.79 12.79 12.79
Shipping Weight
kg
8.40 8.40 8.40 8.40
lbs 18.52 18.52 18.52 18.52
Net Dimensions (W×H×D)
mm
950 x 45 x 950 950 x 45 x 950 950 x 45 x 950 950 x 45 x 950
inches 37.40 x 1.77 x 37.40 37.40 x 1.77 x 37.40 37.40 x 1.77 x 37.40 37.40 x 1.77 x 37.40
Shipping Dimensions (W×H×D)
mm
1,005 x 100 x 1,005 1,005 x 100 x 1,005 1,005 x 100 x 1,005 1,005 x 100 x 1,005
inch 39.57 x 3.94 x 39.57 39.57 x 3.94 x 39.57 39.57 x 3.94 x 39.57 39.57 x 3.94 x 39.57
Functions
Auto restart -
OOOO
Auto swing - OOOO
Group/individual control - OOOO
External contact control - OOOO
Trouble shooting by LED - OOOO
