Product Specifications
Samsung Electronics 2-7
Indoor Unit(cont.)
Q 4WAY casette (Large)
Model
4WAY casette - Large
AM030FN4DCH/AA AM036FN4DCH/AA AM048FN4DCH/AA
Power Supply ø, #, V, Hz 1,2,208-230,60 1,2,208-230,60 1,2,208-230,60
Mode
-
HP/HR HP/HR HP/HR
Performance
Capacity
(Nominal)
Cooling 2)
kW
- --
Btu/h 30,000 36,000 48,000
Heating 2)
kW
- --
Btu/h 34,000 40,000 54,000
Condensate
(with high fan speed)
Liter/h
- --
Power
Power Input
(Nominal)
Cooling 1) W
65 75 95
Heating 2) - 65 75 95
Current Input
(Nominal)
Cooling 1) A
0.5 0.56 0.75
Heating 2) - 0.5 0.56 0.75
Fan
Type -
Turbo Fan Turbo Fan Turbo Fan
Motor
Model -
FMC9731SSB FMC9731SSB FMC9731SSB
Type - BLDC BLDC BLDC
Output x n W 65 x 1 65 x 1 65 x 1
Air Flow Rate H/M/L CMM 22.00 / 19.50 / 17.00 24.00 / 22.00 / 20.00 29.00 / 27.00 / 24.00
External Pressure
Min / Std / Max Pa
---
-WG ---
Sound
Sound Pressure High / Mid / Low dBA
---
Sound Power High / Mid / Low - ---
Refrigerant
Type -
R-410A R-410A R-410A
Control Method - EEV INCLUDED EEV INCLUDED EEV INCLUDED
Temperature Control - Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety devices - Fuse Fuse Fuse
Piping
Connections
Liquid Pipe (Flare)
ø,mm
9.52 9.52 9.52
ø, inch 3/8 3/8 3/8
Gas Pipe (Flare)
ø,mm
15.88 15.88 15.88
ø, inch 5/8 5/8 5/8
Drain Pipe (Quick lock) ø,mm VP25 (OD32,ID25) VP25 (OD32,ID25) VP25 (OD32,ID25)
Dimensions
Net Weight
kg
18.50 18.50 18.50
lbs 40.79 40.79 40.79
Shipping Weight
kg
23.00 23.00 23.00
lbs 50.71 50.71 50.71
Net Dimensions (W×H×D)
mm
840 x 288 x 840 840 x 288 x 840 840 x 288 x 840
inch 33.07 x 11.34 x 33.07 33.07 x 11.34 x 33.07 33.07 x 11.34 x 33.07
Shipping Dimensions (W×H×D)
mm
898 x 357 x 898 898 x 357 x 898 898 x 357 x 898
inch 35.35 x 14.06 x 35.35 35.35 x 14.06 x 35.35 35.35 x 14.06 x 35.35
Panel Size
Panel model -
PC4NUSKFN PC4NUSKFN PC4NUSKFN
Panel Net Weight
kg
5.80 5.80 5.80
lbs 12.79 12.79 12.79
Shipping Weight
kg
8.40 8.40 8.40
lbs 18.52 18.52 18.52
Net Dimensions (W×H×D)
mm
950 x 45 x 950 950 x 45 x 950 950 x 45 x 950
inches 37.40 x 1.77 x 37.40 37.40 x 1.77 x 37.40 37.40 x 1.77 x 37.40
Shipping Dimensions (W×H×D)
mm
1,005 x 100 x 1,005 1,005 x 100 x 1,005 1,005 x 100 x 1,005
inch 39.57 x 3.94 x 39.57 39.57 x 3.94 x 39.57 39.57 x 3.94 x 39.57
Functions
Auto restart -
OOO
Auto swing - OOO
Group/individual control - OOO
External contact control - OOO
Trouble shooting by LED - OOO
