Samsung AM036KN4DCH/AA User Manual

Product Specifications
Samsung Electronics 2-9
Model
Slim1
AM007FNLDCH/AA AM009FNLDCH/AA AM012FNLDCH/AA
Power Supply ø, #, V, Hz 1,2,208-230,60 1,2,208-230,60 1,2,208-230,60
Mode
-
HP/HR HP/HR HP/HR
Performance
Capacity
(Nominal)
Cooling 2)
kW
- --
Btu/h 7,500 9,500 12,000
Heating 2)
kW
- --
Btu/h 8,500 10,500 13,500
Condensate
(with high fan speed)
Liter/h
- --
Power
Power Input
(Nominal)
Cooling 1) W
47 60 75
Heating 2) - 47 60 75
Current Input
(Nominal)
Cooling 1) A
0.32 0.4 0.51
Heating 2) - 0.32 0.4 0.51
Fan
Type -
Sirocco Fan Sirocco Fan Sirocco Fan
Motor
Model -
YSK110-25-6SN YSK110-25-6SN YSK110-25-6SN
Type - SSR SSR SSR
Output x n W 40 x 1 50 x 1 60 x 1
Air Flow Rate H/M/L CMM 8.00 / 7.00 / 6.00 9.00 / 8.00 / 7.00 10.00 / 8.50 / 7.00
External Pressure
Min / Std / Max mmAq
0.00 / 1.00 / 4.00 0.00 / 1.00 / 4.00 0.00 / 1.00 / 4.00
-Pa 0.00 / 9.8 / 39.23 0.00 / 9.8 / 39.23 0.00 / 9.8 / 39.23
Sound
Sound Pressure High / Mid / Low dBA
26.0 / 24.0 / 21.0 27.0 / 25.0 / 23.0 29.0 / 28.0 / 27.0
Sound Power High / Mid / Low - ---
Refrigerant
Type -
R-410A R-410A R-410A
Control Method - EEV INCLUDED EEV INCLUDED EEV INCLUDED
Temperature Control - Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety devices - Fuse Fuse Fuse
Piping
Connections
Liquid Pipe (Flare)
ø,mm
6.35 6.35 6.35
ø, inch 1/4 1/4 1/4
Gas Pipe (Flare)
ø,mm
12.7 12.7 12.7
ø, inch 1/2 1/2 1/2
Drain Pipe (Quick lock) ø,mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Dimensions
Net Weight
kg
24.50 24.50 24.50
lbs 54.01 54.01 54.01
Shipping Weight
kg
28.50 28.50 28.50
lbs 62.83 62.83 62.83
Net Dimensions (W×H×D)
mm
900 x 199 x 600 900 x 199 x 600 900 x 199 x 600
inch 35.43 x 7.83 x 23.62 35.43 x 7.83 x 23.62 35.43 x 7.83 x 23.62
Shipping Dimensions (W×H×D)
mm
1,150 x 280 x 710 1,150 x 280 x 710 1,150 x 280 x 710
inch 45.28 x 11.02 x 27.95 45.28 x 11.02 x 27.95 45.28 x 11.02 x 27.95
Panel Size
Panel model -
---
Panel Net Weight
kg
---
lbs ---
Shipping Weight
kg
---
lbs ---
Net Dimensions (W×H×D)
mm
---
inches ---
Shipping Dimensions (W×H×D)
mm
---
inch ---
Functions
Auto restart -
OOO
Auto swing - XXX
Group/individual control - OOO
External contact control - OOO
Trouble shooting by LED - XXX
Indoor Unit(cont.)
Q SLIM DUCT(Slim1)

Samsung AM036KN4DCH/AA Specifications

General

Brand	Samsung
Model	AM036KN4DCH/AA
Category	Air Conditioner
Language	English
