Samsung AQV09PSBN Service Manual

Samsung Electronics 2-25
2-4 Accessory and Option Specifications
2-4-1 Indoor Unit Accessories
MH FNEA
Item Descriptions Q'TYCode-No. Remark
Indoor
Unit
1
Remote Control 1
Batteries for Remote Control DB47-90024A 2
User Manual DB98-28925A 1
Installation Manual DB98-31791A 1
DB97-02851C
(MH FNEA except MH052FNEA)
DB90-02738A
(MH052FNEA)
DB93-03170Z
The design and shape can be changed according to the model.
Installation Plate
(Plate-Hanger)

Samsung AQV09PSBN Specifications

General

Indoor unit type	Wall-mountable
Indoor unit dimensions (WxDxH)	820 x 205 x 285 mm
Indoor unit noise level (high speed)	36 dB
Outdoor unit dimensions (WxDxH)	790 x 285 x 545 mm
Remotely operated	Yes
Cooling capacity (max)	8500 BTU/h
Heating capacity (max)	11300 BTU/h
Air conditioner functions	cooling, heating
Cooling capacity in watts (max)	2500 W
Heating capacity in watts (max)	3300 W
Airflow	474 m³/h
Power requirements	220 - 240V, 50Hz
Power consumption (cooling) (max)	- W
