35
2. Specification
2-2. Indoor units
(Wind-Free) 4Way Cassette (600x600)
Type
(Wind-Free) 4Way Cassette
(600x600)
(Wind-Free) 4Way Cassette
(600x600)
(Wind-Free) 4Way Cassette
(600x600)
Model Name AJ016TNNDKG/EU AJ020TNNDKG/EU AJ026TNNDKG/EU
Power Supply
Φ, #, V,
Hz
1,2,220-240,50 1,2,220-240,50 1,2,220-240,50
Mode - HP HP HP
Performance Capacity
Cooling
kW 1.60 2.00 2.60
Btu/h 5,500 6,800 8,900
Heating
kW 2.00 2.20 2.90
Btu/h 6,800 7,500 9,900
Power
Power Input
Cooling
W
19.00 19.00 19.00
Heating 19.00 19.00 19.00
Current Input
Cooling
A
0.51 0.51 0.51
Heating 0.51 0.51 0.51
Heat
exchanger
Type - Fin & Tube Fin & Tube Fin & Tube
Material
Fin - Al Al Al
Tube - Cu Cu Cu
Fin Treatment - Green Hydrophile Green Hydrophile Green Hydrophile
Fan
Type - Turbo Fan Turbo Fan Turbo Fan
Quantity EA 1 1 1
Air Flow Rate
m³/min 9.0 / 8.2 / 6.9 9.0 / 8.2 / 6.9 9.0 / 8.2 / 6.9
l/s 150 / 137 / 115 150 / 137 / 115 150 / 137 / 115
External Static
pressure
Max.
(Min/Std/Max)
mmAq - - -
Pa - - -
Fan Motor
Type - BLDC Motor BLDC Motor BLDC Motor
Output x n W 65 x 1 65 x 1 65 x 1
Piping
Connections
Liquid Pipe
Type Flare connection Flare connection Flare connection
Φ, mm
(inch)
6.35 (1/4) 6.35 (1/4) 6.35 (1/4)
Gas Pipe
Type Flare connection Flare connection Flare connection
Φ, mm
(inch)
9.52 (3/8) 9.52 (3/8) 9.52 (3/8)
Heat Insulation -
Both liquid and gas
pipes
Both liquid and gas
pipes
Both liquid and gas
pipes
Drain Pipe Φ,mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Wiring
connections
Communication
Min.
mm
2
0.75 0.75 0.75
Remark - F1, F2 F1, F2 F1, F2
Refrigerant
Type - R32 R32 R32
Electronic Expansion Valve - EEV NOT INCLUDED EEV NOT INCLUDED EEV NOT INCLUDED
Sound
Sound Pressure H/M/L
dB(A)
33 / 29 / 24 33 / 29 / 24 33 / 29 / 24
Sound Power Cooling 49 49 49
External
Dimension
Net Weight kg 11.5 11.5 11.5
Shipping Weight kg 13.5 13.5 13.5
Net Dimensions (W×H×D) mm 575 x 250 x 575 575 x 250 x 575 575 x 250 x 575
Shipping Dimensions (W×H×D) mm 623 x 298 x 653 623 x 298 x 653 623 x 298 x 653
Casing Material - Polypropylene Polypropylene Polypropylene
