2. Specification
Type
(Wind-Free) 4Way Cassette
(600x600)
(Wind-Free) 4Way Cassette
(600x600)
(Wind-Free) 4Way Cassette
(600x600)
Model Name AJ016TNNDKG/EU AJ020TNNDKG/EU AJ026TNNDKG/EU
Panel 1
Model Name - PC4SUFMAN PC4SUFMAN PC4SUFMAN
Type - Wind-Free Wind-Free Wind-Free
Material - HIPS HIPS HIPS
Color - DA White DA White DA White
Net Weight kg 2.7 2.7 2.7
Shipping Weight kg 3.9 3.9 3.9
Net Dimensions (W×H×D) mm 620 x 57 x 620 620 x 57 x 620 620 x 57 x 620
Shipping Dimensions (W×H×D) mm 670 x 120 x 655 670 x 120 x 655 670 x 120 x 655
Panel 2
Model Name - PC4SUSMBN PC4SUSMBN PC4SUSMBN
Type -
Material - HIPS HIPS HIPS
Color - White White White
Net Weight kg 2.7 2.7 2.7
Shipping Weight kg 3.5 3.5 3.5
Net Dimensions (W×H×D) mm 620 x 45 x 620 620 x 45 x 620 620 x 45 x 620
Shipping Dimensions (W×H×D) mm 667 x 102 x 655 667 x 102 x 655 667 x 102 x 655
Drain pump
Drain pump - Included Included Included
Max. lifting Height / Displacement
mm /
Liter/h
750 / 24 750 / 24 750 / 24
Additional
Accessories
Drain pump
External Model - - - -
Internal Model - - - -
Max. lifting Height /
Displacement
mm /
liter/h
- - -
Air Filter -
Option
(Removable /
Washable)
Option
(Removable /
Washable)
Option
(Removable /
Washable)
NOTE
1
)*
Capacities are based on (Equivalent refrigerant piping : 5m, Level differences : 0m)
- Cooling : Indoor temperature : 27°C DB, 19°C WB / Outdoor temperature : 35°C DB, 24°C WB
- Heating : Indoor temperature : 20°C DB, 15°C WB / Outdoor temperature : 7°C DB, 6°C WB
2)* Select wire size based on the value of MCA
3)* Sound pressure level is obtained in an anechoic room.
- Sound pressure level is a relative value, depending on the distance and acoustic environment.
- Sound pressure level may differ depending on operation condition.
- dBA = A-weighted sound pressure level
- Reference acoustic pressure 0 dB = 20uPa
4)* Sound power level is an absolute value that a sound source generates.
- dBA = A-weighted sound power level
- Reference power : 1pW
- Measured according to ISO 3741
