4. Combination Table4. Combination Table
Outdoor unit A B C D E
Heating
Capacity
Capacity
Power
Consumption
Current
Efc.
NOM.
Heating.
At
7℃/20℃
SEASONAL
EFFICIENCY
(ACCORDING
EN14825)
SCOP
P
design
Qhe
W W W A
A B C D E MIN STD MAX MIN STD MAX MIN STD MAX COP Class kW kWh
AJ100TXJ5KG 4 Unit
7 7 7 7 2200 2200 2200 2200 1400 8800 9800 520 2110 2700 2.4 9.0 12.4 4.18 A+ 4.25 7.91 2607
7 7 7 9 2140 2140 2140 3210 1560 9630 11380 520 2320 3120 2.4 9.9 14.3 4.15 A+ 4.25 7.9 1 2607
7 7 7 12 2010 2010 2010 3660 1590 9690 12170 530 2330 3330 2.4 9.9 15.2 4.15 A+ 4.25 7.9 1 2607
7 7 7 18 1730 1730 1730 4710 1780 9900 12170 540 2410 3350 2.5 10.3 15.3 4.11 A+ 4.25 7.91 2607
7 7 7 24 1630 1630 1630 5770 1960 10660 12320 560 2620 3410 2.6 11.2 15.6 4.07 A+ 4.25 7.9 1 2607
7 7 9 9 1950 1950 2920 2920 1560 9740 11530 520 2350 3160 2.4 10.0 14.5 4.15 A+ 4.25 7.9 1 2607
7 7 9 12 1840 1840 2760 3350 1590 9790 11850 530 2390 3250 2.4 10.2 14.9 4.09 A+ 4.25 7.91 2607
7 7 9 18 1610 1610 2410 4380 1890 10010 12170 540 2440 3350 2.5 10.4 15.3 4.11 A+ 4.25 7.9 1 2607
7 7 9 24 1530 1530 2290 5410 1960 10760 12480 560 2620 3450 2.6 11.2 15.8 4.10 A+ 4.25 7.9 1 2607
7 7 12 12 1750 1750 3190 3190 1750 9880 12170 530 2360 3340 2.4 10.1 15.3 4.19 A+ 4.25 7.91 2607
7 7 12 18 1630 1630 2960 4440 1930 10660 12320 550 2610 3390 2.5 11.1 15.5 4.09 A+ 4.25 7.9 1 2607
7 7 12 24 1470 1470 2670 5210 2280 10820 12800 570 2630 3540 2.6 11.2 16.2 4.11 A+ 4.25 7.9 1 2607
7 7 18 18 1460 1460 3970 3970 2240 10860 12800 560 2640 3530 2.6 11.2 16.2 4.11 A+ 4.25 7.91 2607
7 7 18 24 1330 1330 3630 4710 2320 11000 12960 580 2680 3600 2.7 11.4 16.5 4.10 A+ 4.25 7.9 1 2607
7 9 9 9 1790 2690 2690 2690 1720 9860 12170 520 2390 3330 2.4 10.2 15.2 4.13 A+ 4.25 7.91 2607
7 9 9 12 1710 2560 2560 3100 1750 9930 12320 530 2410 3370 2.4 10.3 15.4
4.12 A+ 4.25 7.9 1 2607
7 9 9 18 1590 2380 2380 4330 1890 10680 12480 540 2620 3430 2.5 11.2 15.7 4.08 A+ 4.25 7.9 1 2607
7 9 9 24 1440 2160 2160 5100 2240 10860 12960 560 2670 3580 2.6 11.4 16.4 4.07 A+ 4.25 7.91 2607
7 9 12 12 1630 2440 2960 2960 1860 9990 12170 530 2440 3340 2.4 10.4 15.3 4.10 A+ 4.25 7.9 1 2607
7 9 12 18 1530 2290 2780 4170 1930 10770 12480 550 2640 3440 2.5 11.2 15.7 4.08 A+ 4.25 7.9 1 2607
7 9 12 24 1400 2100 2540 4960 2280 11000 12960 570 2680 3580 2.6 11.4 16.4 4.11 A+ 4.25 7.91 2607
7 9 18 18 1390 2070 3770 3770 2240 11000 12960 560 2680 3580 2.6 11.4 16.4 4.11 A+ 4.25 7.91 2607
7 9 18 24 1250 1880 3420 4450 2320 11000 13110 580 2680 3640 2.7 11.4 16.7 4.11 A+ 4.25 7.91 2607
7 12 12 12 1560 2830 2830 2830 1890 10050 12320 540 2420 3380 2.5 10.3 15.5 4.15 A+ 4.25 7.9 1 2607
7 12 12 18 1470 2670 2670 4010 2200 10820 12800 550 2650 3520 2.5 11.3 16.1 4.08 A+ 4.25 7.9 1 2607
7 12 12 24 1350 2440 2440 4770 2280 11000 12960 570 2680 3590 2.6 11.4 16.4 4.11 A+ 4.25 7.91 2607
7 12 18 18 1330 2410 3630 3630 2280 11000 12960 570 2680 3580 2.6 11.4 16.4 4.11 A+ 4.25 7.9 1 2607
7 12 18 24 1210 2200 3300 4290 2360 11000 13430 590 2680 3730 2.7 11.4 1 7.1 4.11 A+ 4.25 7.91 2607
7 18 18 18 1190 3270 3270 3270 2320 11000 13430 580 2680 3720 2.7 11.4 17.0 4.11 A+ 4.25 7.91 2607
9 9 9 9 2490 2490 2490 2490 1820 9960 12480 520 2310 3410 2.4 9.8 15.6 4.32 A+ 4.32 7.9 1 2564
9 9 9 12 2380 2380 2380 2880 1860 10020 12320 530 2340 3370 2.4 10.0 15.4 4.28 A+ 4.25 7.9 1 2607
9 9 9 18 2240 2240 2240 4080 2160 10800 12800 540 2610 3510 2.5 11.1 16.1 4.14 A+ 4.25 7.91 2607
9 9 9 24 2050 2050 2050 4850 2240 11000 12960 560 2680 3580 2.6 11.4 16.4 4.11 A+ 4.25 7.9 1 2607
9 9 12 12 2410 2410 2920 2920 1860 10660 12480 530 2510 3420 2.4 10.7 15.7 4.24 A+ 4.25 7.91
2607
9 9 12 18 2160 2160 2620 3930 2200 10870 12960 550 2630 3560 2.5 11.2 16.3 4.13 A+ 4.25 7.91 2607
9 9 12 24 1970 1970 2400 4660 2280 11000 13110 570 2680 3620 2.6 11.4 16.6 4.11 A+ 4.25 7.9 1 2607
9 9 18 18 1950 1950 3550 3550 2240 11000 13110 560 2680 3620 2.6 11.4 16.6 4.11 A+ 4.25 7.91 2607
9 9 18 24 1780 1780 3240 4200 2320 11000 13590 580 2680 3760 2.7 11.4 1 7. 2 4.11 A+ 4.25 7.91 2607
9 12 12 12 2320 2810 2810 2810 1890 10750 12480 540 2600 3430 2.5 11.1 15.7 4.13 A+ 4.25 7.91 2607
9 12 12 18 2100 2540 2540 3820 2200 11000 12960 550 2680 3570 2.5 11.4 16.3 4.11 A+ 4.25 7.9 1 2607
9 12 12 24 1910 2300 2300 4490 2280 11000 13110 570 2680 3630 2.6 11.4 16.6 4.11 A+ 4.25 7.91 2607
9 12 18 18 1880 2280 3420 3420 2280 11000 13110 570 2680 3620 2.6 11.4 16.6 4.11 A+ 4.25 7.91 2607
12 12 12 12 2700 2700 2700 2700 2160 10800 12800 540 2610 3510 2.5 11.1 16.1 4.14 A+ 4.25 7.91 2607
12 12 12 18 2440 2440 2440 3680 2240 11000 12960 560 2680 3570 2.6 11.4 16.3 4.11 A+ 4.25 7.91 2607
12 12 12 24 2220 2220 2220 4340 2320 11000 13430 580 2680 3720 2.7 11.4 17.0 4.11 A+ 4.25 7.91 2607
12 12 18 18 2200 2200 3300 3300 2280 11000 13430 570 2680 3710 2.6 11.4 17.0 4.11 A+ 4.25 7.9 1 2607
