4. Combination Table4. Combination Table
Outdoor unit A B C D E
Heating
Capacity
Capacity
Power
Consumption
Current
Efc.
NOM.
Heating.
At
7℃/20℃
SEASONAL
EFFICIENCY
(ACCORDING
EN14825)
SCOP
P
design
Qhe
W W W A
A B C D E MIN STD MAX MIN STD MAX MIN STD MAX COP Class kW kWh
AJ100TXJ5KG 5 Unit
7 7 7 7 7 2200 2200 2200 2200 2200 1650 11000 13110 550 2560 3610 2.5 11.7 16.5 4.30 A+ 4.25 7.91 2607
7 7 7 7 9 2080 2080 2080 2080 3120 1820 11440 12960 550 2670 3570 2.5 12.2 16.3 4.28 A+ 4.25 7.91 2607
7 7 7 7 12 1990 1990 1990 1990 3620 1850 11580 13110 560 2720 3610 2.6 12.4 16.5 4.26 A+ 4.25 7.91 2607
7 7 7 7 18 1710 1710 1710 1710 4660 2000 11500 13430 570 2700 3710 2.6 12.3 17.0 4.26 A+ 4.25 7.9 1 2607
7 7 7 7 24 1580 1580 1580 1580 5610 2360 11930 13750 590 2810 3810 2.7 12.8 17.4 4.24 A+ 4.25 7.9 1 2607
7 7 7 9 9 1950 1950 1950 2930 2930 1930 11710 13430 550 2750 3690 2.5 12.5 16.9 4.26 A+ 4.25 7.91 2607
7 7 7 9 12 1880 1880 1880 2820 3420 1960 11880 13110 560 2800 3610 2.6 12.7 16.5 4.24 A+ 4.25 7.9 1 2607
7 7 7 9 18 1630 1630 1630 2440 4450 2280 11780 13590 570 2790 3750 2.6 12.7 1 7. 2 4.22 A+ 4.25 7.9 1 2607
7 7 7 9 24 1490 1490 1490 2240 5290 2360 12000 13900 590 2820 3860 2.7 12.8 17. 7 4.26 A+ 4.25 7.91 2607
7 7 7 12 12 1730 1730 1730 3140 3140 1960 11470 13430 560 2680 3700 2.6 12.2 16.9 4.28 A+ 4.25 7.9 1 2607
7 7 7 12 18 1580 1580 1580 2880 4320 2320 11940 13750 580 2830 3800 2.7 12.9 17. 4 4.22 A+ 4.25 7.91 2607
7 7 7 12 24 1430 1430 1430 2620 5090 2400 12000 14000 600 2830 3940 2.7 12.9 18.0 4.24 A+ 4.25 7.9 1 2607
7 7 7 18 18 1420 1420 1420 3870 3870 2360 12000 14000 590 2830 3940 2.7 12.9 18.0 4.24 A+ 4.25 7.9 1 2607
7 7 9 9 9 1840 1840 2760 2760 2760 1930 11960 13430 550 2810 3690 2.5 12.8 16.9 4.26 A+ 4.25 7.91 2607
7 7 9 9 12 1690 1690 2540 2540 3080 1960
11540 13590 560 2700 3740 2.6 12.3 1 7.1 4.28 A+ 4.25 7.91 2607
7 7 9 9 18 1550 1550 2330 2330 4240 2280 12000 13900 570 2820 3840 2.6 12.8 1 7. 6 4.26 A+ 4.25 7.91 2607
7 7 9 9 24 1400 1400 2110 2110 4980 2360 12000 14000 590 2820 3940 2.7 12.8 18.0 4.26 A+ 4.25 7.9 1 2607
7 7 9 12 12 1640 1640 2470 2990 2990 2240 11730 13590 560 2750 3740 2.6 12.5 17.1 4.26 A+ 4.25 7.91 2607
7 7 9 12 18 1490 1490 2240 2710 4070 2320 12000 13900 580 2840 3840 2.7 12.9 17. 6 4.22 A+ 4.25 7.9 1 2607
7 7 9 12 24 1350 1350 2040 2460 4800 2400 12000 14000 600 2840 3940 2.7 12.9 18.0 4.22 A+ 4.25 7.91 2607
7 7 9 18 18 1340 1340 2020 3650 3650 2360 12000 14000 590 2840 3940 2.7 12.9 18.0 4.22 A+ 4.25 7.91 2607
7 7 12 12 12 1600 1600 2900 2900 2900 2280 11900 13750 570 2780 3790 2.6 12.6 1 7. 3 4.28 A+ 4.25 7.9 1 2607
7 7 12 12 18 1430 1430 2610 2610 3920 2320 12000 14000 580 2840 3930 2.7 12.9 18.0 4.22 A+ 4.25 7.9 1 2607
7 9 9 9 9 1670 2500 2500 2500 2500 1930 11670 13590 550 2720 3730 2.5 12.4 1 7.1 4.29 A+ 4.25 7.91 2607
7 9 9 9 12 1620 2420 2420 2420 2940 2240 11820 13750 560 2760 3780 2.6 12.6 1 7. 3 4.28 A+ 4.25 7.9 1 2607
7 9 9 9 18 1460 2190 2190 2190 3970 2280 12000 14000 570 2830 3920 2.6 12.9 1 7.9 4.24 A+ 4.25 7.9 1 2607
7 9 9 9 24 1330 1990 1990 1990 4700 2360 12000 14000 590 2830 3940 2.7 12.9 18.0 4.24 A+ 4.25 7.9 1 2607
7 9 9 12 12 1570 2350 2360 2860 2860 2240 12000 13900 560 2820 3830 2.6 12.8 1 7. 5 4.26 A+ 4.25 7.91 2607
7 9 9 12 18 1400 2110 2110 2550 3830 2320 12000 14000 580 2870 3920 2.7 13.0 1 7.9 4.18 A+ 4.25 7.91 2607
7 9 9 12 24 1290 1920 1920 2330 4540 2400 12000 14000 600 2870 3940 2.7 13.0 18.0 4.18 A+ 4.25 7.91 2607
7 9 9 18 18 1280 1900 1900 3460 3460 2360 12000 14000 590 2860 3940 2.7 13.0 18.0 4.20 A+ 4.25 7.9 1 2607
7 9 12
12 12 1520 2260 2740 2740 2740 2280 12000 13900 570 2850 3830 2.6 12.9 17. 5 4.21 A+ 4.25 7.9 1 2607
7 9 12 12 18 1360 2030 2460 2460 3690 2320 12000 14000 580 2850 3930 2.7 12.9 18.0 4.21 A+ 4.25 7.91 2607
7 12 12 12 12 1440 2640 2640 2640 2640 2280 12000 14000 570 2830 3920 2.6 12.9 1 7.9 4.24 A+ 4.25 7.91 2607
9 9 9 9 9 2400 2400 2400 2400 2400 3400 12000 14000 550 2820 3900 2.5 12.8 17.8 4.26 A+ 4.25 7.9 1 2607
9 9 9 9 12 2300 2300 2300 2300 2800 2240 12000 13900 560 2820 3820 2.6 12.8 17. 5 4.25 A+ 4.25 7.91 2607
9 9 9 9 18 2060 2060 2060 2060 3760 2280 12000 14000 570 2840 3920 2.6 12.9 1 7.9 4.23 A+ 4.25 7.9 1 2607
9 9 9 9 24 1890 1890 1890 1890 4440 2360 12000 14000 590 2840 3940 2.7 12.9 18.0 4.23 A+ 4.25 7.91 2607
9 9 9 12 12 2210 2210 2210 2680 2690 2240 12000 14000 560 2840 3910 2.6 12.9 1 7.9 4.23 A+ 4.25 7.9 1 2607
9 9 9 12 18 1990 1990 1990 2410 3620 2320 12000 14000 580 2830 3920 2.7 12.9 17.9 4.24 A+ 4.25 7.9 1 2607
9 9 12 12 12 2130 2130 2580 2580 2580 2280 12000 14000 570 2840 3910 2.6 12.9 1 7.9 4.23 A+ 4.25 7.91 2607
9 9 12 12 18 1920 1920 2330 2330 3500 3400 12000 14000 580 2850 3930 2.7 12.9 18.0 4.21 A+ 4.25 7.91 2607
9 12 12 12 12 2040 2490 2490 2490 2490 2280 12000 14000 570 2850 3920 2.6 12.9 1 7.9 4.21 A+ 4.25 7.91 2607
NOTE
1
EER and COP declared only for the purpose of tax deductions in force at the time of the creation of this catalog.
2
The above is the value for connecting with the following indoor units.
- Wind Free(PRM) : AR07TXCAAWK, AR09TXCAAWK, AR12TXCAAWK
3
You can not connect a single unit.
4
Power consumption include indoor unit power.
