Air Conditioning Unit - Main Parts, Buttons and Display
Air inlet (inside)
Air filter
(The air filter is
located inside)
Inner air flow blades
(right/left orientation)
Air outlet
Outer air flow blades
(up/down orientation)
Air inlet (Outside)
Ventilation lever
Power plug
(The type of the power
plug may differ according
to the type of local power
supply.)
Fan speed indicators
(LOW, MED, HIGH)
Temperature/Timer
settings
Temperature adjustment
buttons
Operating mode indicators
(COOL, FAN, HEAT)
Remote Control sensor
Air flow blade swing button
Fan speed adjustment
button
Air flow blade swing indicator
Sleep timer setting button
Timer indicator
Deice indicator
ON/OFF button
Operating mode selection
button(COOL, FAN, HEAT)
Timer setting button
❄ The design and shape are subject to
change according to the model.
