Samsung B1630N

5-3
5. Exploded View & Part List
5-2. LS20PUYKF/EN - Parts List
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
0.1 BN90-02395A ASSY COVER FRONT;B2030,H/GLOSSY 1 SNA
..2 T0003 BN96-12497A
ASSY COVER P-FRONT;PLUM
20,ABS+PMMA,HB,B
1 SA
...3 W392 6003-000282 SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 SA
...3 BN61-05972A GUIDE-PANEL;PLUM 23,SECC,T0.8 1 SNA
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.04,680mm,20 0.45 SNA
...3 M0112 BN63-06350A
COVER-FRONT;PLUM
20,PMMA+ABS,HB,BK23,SF-
1 SNA
...3 BN64-01234A DECORATION;PLUM 20,PC,CLEAR 1 SNA
...3 AL093 BN67-00280A LENS-LED;PLUM23'',PC CLEAR,TP26 1 SNA
...3 T0527 BN68-00798D LABEL-ENERGY,STAR;L/M,W/W,PET,T0.05,9.3, 1 SNA
...3 M0175 BN96-12804B ASSY BOARD P-TOUCH FUNCTION;plum (all mo 1 SA
....4 BN94-03258A
ASSY PCB FUNCTION-BN96-
12804B;PLUM,BN96-
1 SNA
.....5 M2893 BN39-01164C
LEAD CONNECTOR;plum,UL1061#28,5P,80mm
,12
1 SA
.....5 BN61-05967A HOLDER-CONTROL;plum23",ABS HB,WH12 1 SNA
.....5 BN97-03998A ASSY SMD-BN96-12804B;PLUM,BN96-12804B 1 SNA
......6 0406-001253 DIODE-TVS;VESD05A1-02V,6.0/6.8/7.5V,SOD- 2 SNA
......6 L0405 0601-002642 LED;SMD(SIDE VIEW),BLUE,475nm,3.8x1.0x0. 1 SNA
......6 1209-001890
IC-SENSOR;CT1N07B,MLF,24P,4x4mm,PLAST
IC,
1 SA
......6 HDR7 2007-000139 R-CHIP;220ohm,5%,1/16W,TP,1005 6 SNA
......6 MR306 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 2 SNA
......6 R111 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 2 SNA
......6 2007-001329 R-CHIP;7.5Kohm,5%,1/16W,TP,1005 2 SA
......6 AD480 2203-006399 C-CER,CHIP;1000nF,10%,6.3V,X5R,1005 1 SA
......6 CN906 3711-007275
CONNECTOR-
HEADER;BOX,5P,1R,1.25mm,SMD-S,
1 SA
......6 BN41-01342A PCB SUB-TOUCH FUNCTION;Plum(all),FR-4,2, 1 SNA
.....5 BN74-00057A
TAPE-FUNCTION;DOUBLE FACE
TAPE,Polyester
1 SNA
.....5 BN74-00058A
TAPE-FUNCTION;DOUBLE FACE
TAPE,Polyester
2 SNA
...3 M0081 6003-000115
SCREW-TAPTYPE;BH,+,B,M3,L6,ZPC(BLK),SW
RC
2 SNA
..2 BN68-02526A
LABEL-MONITOR-POP;Plum
POP,WW,PET,T0.05,
1 SNA
0.1 M0002 BN90-02396B ASSY COVER REAR;B2030N,HIGH GLOSSY 1 SNA
..2 W391 6003-000275
SCREW-TAPTYPE;BH,+,B,M3,L10,ZPC(BLK),S
WR
2 SA
..2 M0013 BN96-12499B ASSY COVER P-REAR;PLUM 20 analog,HIPS,HB 1 SA
...3 M0081 6003-001001
SCREW-TAPTYPE;FH,+,B,M3,L8,ZPC(BLK),SW
RC
1 SNA
...3 M0081 6003-001239
SCREW-TAPTYPE;FH,+,B,M4,L10,ZPC(WHT),S
WR
2 SNA
...3 M0113 BN61-01581A BRACKET-VESA;BI17/19BS,SECC,T1.0 2 SNA
...3 T0060 BN61-05091A SPRING ETC-STAND;ECOFIT 23",SK5,T0.3 1 SNA
...3 T0060 BN61-05968A SPRING ETC;PLUM 23,SK5,T0.6,BLACK 1 SNA
...3 CIS4 BN61-05971A HOLDER-STAND;PLUM 23,POM,WHITE,ACETAL 1 SNA
