Samsung B1930HD - Page 6

3-3
3. Disassembly and Assembly
Description Photo Screws
4. Turn the monitor over again to remove the back
cover.
5. After disassembling the Rear-Cover, prepare for
the internal disassembly as shown in the picture
on the right.
LAMP
WIRE
LVDS
Screws
Function&Speaker wire
6. Remove the LVDS cable.
7. Remove the Lamp wire.
