Samsung B1930HD - 5-2. Parts List

5-2
5. Exploded View & Part List
5-2. LS23PTDSF/EN Parts List
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
LS23PTDSF/EN
0.1 BN90-02391D ASSY COVER FRONT;cancel 1 SNA
..2 F001A BN96-12455E ASSY COVER P-FRONT;Plum MFM 23 (B2330HD) 1 SA
...3 W392 6003-000282 SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW 4 SA
...3 BN61-06447A HOLDER-BOSS;PLUM_MFM_23,HIPS,BK23,HB 1 SNA
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.8 SNA
...3 F001 BN63-06311B COVER-FRONT;PLUM MFM 23",ABS+PMMA,HB,BK0 1 SNA
....4 0103-007303 RESIN-PMMA;BK0035,UL-94 HB,PMMA+ABS,tran 219 SNA
...3 BN64-01211A DECORATION;PLUM 23,PC,CLEAR 1 SNA
...3 AL093 BN67-00280A LENS-LED;PLUM23'',PC CLEAR,TP26 1 SNA
...3 T0527 BN68-00798D LABEL-ENERGY,STAR;L/M,W/W,PET,T0.05,9.3, 1 SNA
...3 AS100 BN63-07438A SHEET-LED;30-MFM,PC SHEET,T0.2,BLK 2 SNA
...3 FB01A BN96-15120B ASSY BOARD P-FUNCTION;B2230HN,CT5000-796 1 SA
..2 SP01A BN96-12940D ASSY SPEAKER P;16ohm,4pin,3W,L:60 R:270 1 SA
..2 BN68-03085B LABEL-MONITOR-POP;30 MFM POP,WW,PET,T0.0 1 SNA
0.1 R001A BN90-02902A ASSY COVER REAR;LS23PTDSF/EN,30-MFM 1 SNA
..2 W391 6003-000275 SCREW-TAPTYPE;BH,+,B,M3,L10,ZPC(BLK),SWR 2 SA
..2 R001A BN96-14964A ASSY COVER P-REAR;Plum MFM 23 (B2330HD), 1 SA
...3 M0081 6003-001001 SCREW-TAPTYPE;FH,+,B,M3,L8,ZPC(BLK),SWRC 1 SNA
...3 M0081 6003-001239 SCREW-TAPTYPE;FH,+,B,M4,L10,ZPC(WHT),SWR 2 SNA
...3 T0060 BN61-05091A SPRING ETC-STAND;ECOFIT 23",SK5,T0.3 1 SNA
...3 T0060 BN61-05968A SPRING ETC;PLUM 23,SK5,T0.6,BLACK 1 SNA
...3 CIS4 BN61-05971A HOLDER-STAND;PLUM 23,POM,WHITE,ACETAL 1 SNA
...3 CB19 BN61-06509A BRACKET-VESA;PLUM MFM,EGI-SECC,T0.8 4 SNA
...3 BN63-06317A SHIELD-LAMP;PLUM 23'',SPTE,T0.3 1 SNA
...3 R001 BN63-06980A COVER-REAR;PLUM_MFM_23,ABS,HB,BK23,EUROP 1 SNA
...3 SC05 BN63-06981A COVER-STAND;PLUM_MFM_23,ABS+PMMA,HB,BK23 1 SNA
...3 T0071 BN64-01397A INLAY-TERMINAL;PLUM MFM,PS SHEET,T0.3,EU 1 SNA
...3 M0131 BP63-00786A GASKET;HLS6187WX/XAA,Conductive Adhesive 1 SNA
...3 BN74-00031A GREASE;kanto-kasei FL-955,grease,wht 0.15 SNA
0.1 BN91-02922A ASSY LCD;LTM230HT01,Cream-MFM 23" 1 SNA
..2 M0215 BN07-00609A LCD-PANEL;LTM230HT01,SSRZTS,6Bit + Hi-FR 1 SA
0.1 M0017 BN91-05542E ASSY CHASSIS;LS23PTDSF/EN 1 SNA
..2 T0081 6001-002408 SCREW-MACHINE;BH,+,WT,M4,L12,ZPC(WHT),SW 2 SA
..2 M0081 6003-000264 SCREW-TAPTYPE;PWH,+,-,B,M3,L6,ZPC(WHT),S 5 SA
..2 T0562 6046-001014 STAND OFF;#4-40,L6,NI PLT,C3601 2 SNA
..2 P001A BN44-00392A AC VSS(I);IP-65155A,PLUM23,24"w(MFM),0.7 1 SA
..2 CCMM1 BN73-00152A SILICON/RUBBER;LNT4661FX/XAA,FILLER,19x1 1 SNA
..2 M0014 BN94-02646E ASSY PCB MAIN;LS23PTDSF/EN 1 SA
...3 0202-001557 SOLDER-CREAM;LST57-A,D38-63,42SN/57BI/1A 3 SNA
...3 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.25 SNA
...3 3701-001658 CONNECTOR-DSUB;15P,3ROW,FEMALE,STARAIGHT 1 SA
...3 HB01A 3711-000058 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5MM,AN 1 SA
...3 CN906 3711-004105 CONNECTOR-HEADER;BOX,8P,1R,2.5mm,ANGLE,S 1 SA
...3 DRVCN1 3711-004379 HEADER-BOARD TO CABLE;BOX,4P,1R,2mm,STRA 1 SA
...3 JA330 3722-002176 JACK-PHONE;7P/4C,SN,L-BLU,STRAIGHT 1 SA
