English
1
5. After unscrewing and removing Five
screws, disassemble the ASSY HINGE MID
(1).
2
6. Remove the door by carefully lifting the
door (2).
CAUTION
Be careful not to scratch.
7. Use the screwdriver to loosen and remove
the upper, middle, and bottom hinges on
the fridge's door or the freezer's door in
the arrow direction as shown.
8. Reassemble in the opposite order of
disassembly after replacing the Hinge Up,
Hinge Mid, and/or Hinge Low.
CAUTION
• Make sure the wire connectors are
connected properly.
• Be careful not to damage the wires when
fastening the top cover.
