7-2 Main Parts List
7-2 Samsung Electronics
Exploded Views and Parts List
Ref. No. Parts No. Description/Specification Q'ty Remarks
1 DE70-30029B PANEL-OUTER;SECC T0.6 W405.5 L1180.8 1
2 DE63-90035G CUSHION-RUBBER;DFA20 T2 W190 L100 BLK 1
3 DE61-50073D BRACKET-UPPER;ALSTAR T0.6 W273 L432 MB6544W 1
4 DE61-70060A SPRING-PLATE;SK-5 T0.5 1
5 DE61-30185A SUPPORTER-HEATER;ALUMINA T12 NTR 1
7 DE47-70031B HEATER-GRILL;D6.8 230V 1400W 37.0OHM RE-1300 1
8 DE60-40009B WASHER-TEFLON; SLOT ID22.2 OD28 T1.2 TEFLON 1
9 DE63-20017A GASKET-HEATER;BRASS T1.5 OD30.5 ID22.5 1
10 DE60-90006A FLANGE-RING;C3604BD ID22.1 OD26 L4.7 MBGF45 1
11 DE61-50177A BRACKET-EARTH;BSS2-A T1.0 W28 L38 M9GF45 1
12 DE61-50115A BRACKET-HEATER;BSS2-A T1.0 W55 L55.5 M9GF45 1
13 DE61-50076A BRACKET-AIR GUIDE;ALCOAT T0.8 W61 L218.5 1
14 DE65-20014A CABLE-CLAMP;DA6-N NY 66 1
15 DE39-20058B ASSY POWER CORD;KKP-4819D/B232 1.5MM 250V16 1
16 DE71-60058C COVER-BACK;SCP2(CR) T0.6 W385.5 L275 BLK-CO 1
17 DE91-40042A ASSY NOISE FILTER;DNA-1019(C)250V 10A CMO- 1
18 DE61-30129A SUPPORT-P.C.B;DASS-T9N 2
19 DE31-10080A MOTOR-FAN;AMM92-002AUEE 230V0.20A MIN2550RPM 1
20 DE39-40285A WIRE HARNESS-A;230V50HZ RE-1300 1
21 4713-000168 LAMP-INCANDESCENT;230V,-,25W,ORG,-,-, 1
22 DE65-20031A BUSHING;DASB-16N 17.8X6.3 NYLON NTR SHORT BUSHING 1
23 DE63-90065E CUSHION-LAMP;PUT-FOAM T40 W10 L90 M6245 1
24 DE01-00051A FILM-LAMP;T0.25 W105 L85 CLEAR RE-1300 1
25 DE66-90013A LEVER-DOOR;POM(F20-01) NTR MW5630T 1
26 DE62-90046A ADIABATIC-RIGHT;T3 W219.3 L214.8 RE-1300 1
27 DE71-60294A COVER-ADIABATIC;SECC T0.6 W249.7 L353.5 RE-1300 1
28 DE61-30132A SUPPORTER-MGT;SECC T0.6 W38 L342.5 MW6630T 1
29 DE47-40029A SOCKET-LAMP;250V2A 22.230 E14 BJB 1
30 DE47-20031A THERMOSTAT;PW-2N 140/30 1
31 DE03-30035A MAGNETRON;OM75PH(31)ESS 1
32 DE92-90213A ASSY COVER-AIR; RE-1300 1
33 DE93-20019B ASSY BODY LATCH;M8145G NEW LATCH 1
34 72681-0004-001 LATCH-BODY;POM 50G M8135G NEW LATCH 1
35 3405-000178 SW-MICRO;VP-533A-OF-PS(T85) 250V,15A,20 2
36 3405-000175 SW-MICRO;VP-531-OF (T85) 250V,15A,200GF 1
37 71533-0011-00 LEVER-SWITCH(A);POM 10G NTR MX245 1
38 71533-0012-00 LEVER-SWITCH(B);POM 12G NTR MX245 1
39 DE59-40001A DIODE-H.V;HVR-1X-32B-12 1
40 DE91-70061A ASSY-H.V.FUSE;THV060T-0800-H 5KV/0.8A RED 1
: Option Parts : Warning
:Electrostatically Sensitive Devices
To Next Page
