Samsung Electronics 7-3
7-2 Main Parts List
Ref. No. Parts No. Description/Specification Q'ty Remarks
41 DE26-20084A TRANS-L.V;RE-1280STC RE-1 230V 50HZ AC16/3V 1
42 DE61-40026A FOOT;P.P JI350 BLK 4
43 DE60-60025A PIN-FOOT;P.P-JI350BLK 4
44 DE61-50106A BRACKET-H.V.C;SECC T0.8 W31 L125.8 1
45 2501-001030 C-OIL;1.1uF,2100V,BK,35x54x95,200mm 1
46 DE26-10042B TRANS-H.V;Y9245NTC-1 230V 50HZ AC2230V 1
47 DE63-90065J CUSHION-GUIDE;PUT FOAM T40 W10 L460 MX246 1
48 DE80-10031B BASE-PLATE;SGCC1-Z T0.8 W375 L588 RE-1300 1
49 DE65-20025A CABLE-CLAMP;DAWS-2NB NYLON66 NTR WIRE SADDL 1
50 DE31-10097A MOTOR-SYNCHRONOUS;M2LJ24ZS52 220/240V50/60HZ M6235 1
51 DE47-20050A THERMOSTAT;PW-2N 130/60 2
52 DE71-60313A COVER-CEILING;MICA SHEET T0.5 W48.5 L117 RE-1300 1
53 DE61-80036A HINGE-LOWER;SCP1 T3.0 W24.7 L91.2 BLK-COAT 1
54 DE61-80037G HINGE-UPPER;SCP1 T3.0 W26 L76 BLK-COAT MB24 1
55 DE32-10013A SENSOR-THERMISTOR;PT-312-K2 1
56 DE72-60035Q GUIDE-AIR;SECC (T)0.6 (W)240 (L)242 5 RE-13 1
57 DE39-40339A WIRE HARNESS-C;230V50HZ RE-1300 1
58 DE39-40409A WIRE HARNESS-E;230V50HZ M9G45 CTW 1
59 DE39-30074B WIRE LEAD-C;L170 1
60 ASSY CONTROL-BOX 1
61 ASSY DOOR 1
62 DE63-90062A CUSHON-RUBBER DOOR;RUBBER(CR) T9 W30 L50 1
63 DE74-20025C TRAY-CONVECTION;SPP T0.8 W12 L325.9 CE104CF 1
64 DE74-20016A TRAY-COOKING;GLASS T5.0 PI345 1250G M551T 1
65 DE92-90189C ASSY-GUIDE ROLLER;D22.5 RE-1300 1
66 DE67-60028A COUPLER;PTFE 20G WHT RE-1300 1
67 DE92-90019P ASSY-WIRE RACK;CE1279KSE HIGH 1
68 DE92-90019R ASSY-WIRE RACK);CE1279KSE LOW 1
69 DE65-20012A CORD-CLAMP;DALC-2-1 SILICI 1
Exploded Views and Parts List
