Samsung CE108MDF - CONTROL PANEL; Control Panel Layout; OVEN; Oven Components

3
ENGLISH
OVEN
1. DOOR HANDLE
2. VENTILATION HOLES
3. HEATING ELEMENT
4. VENTILATION HOLES
5. WATER BOWL HOLDER
6. DOOR LATCHES
7. DOOR
8. TURNTABLE
9. COUPLER
10. ROLLER RING
11. SAFETY INTERLOCK HOLES
12. CONTROL PANEL
CONTROL PANEL
1. DISPLAY
2. POWER DEFROST FEATURE
BUTTON
3. AUTO REHEAT FEATURE
BUTTON
4. MICROWAVE BUTTON
5. CONVECTION BUTTON
6. GRILL BUTTON
7. DIAL KNOB (Cook time, Weight
and serving size)
8. STOP / CANCEL BUTTON
9. CLOCK SETTING BUTTON
10. INDIAN RECIPE BUTTON
11. STEAM CLEAN BUTTON
12. AUTO FAST PREHEAT
SELECTION BUTTON
13. MICROWAVE+CONVECTION
BUTTON
14. COMBI BUTTON
15. START / +30S BUTTON
9
1
2
3
4
5
6
7
8
10
11
12
13
14
15
9 10 11 128
1 2 3
6 7
54
