Samsung DA68 - How to Adjust Door Height

English - 22
• If the Refrigerator is not level back and
front, put a solid panel (such as a plastic
panel, a plastic ruler, etc.) on the fl oor
where the rear legs will rest, and then fi x
it in place with plastic tape.
When you push in the Refrigerator, make
sure the rear legs rest on the panel.
• If you have a wooden fl oor or similar soft fl oor,
take care not to damage the fl oor when pushing
the Refrigerator into place.
HOW TO ADJUST THE DOOR HEIGHT
If any one of the doors is lower
than the other:
• Check if the Refrigerator is
level before adjusting the
door.
• Adjust the door height di erence by inserting
a Snap Ring (
1
1
) as shown between the door
and the hinge.
You can use the rings to raise the right side
door of the fresh food compartment and both
doors of the freezer compartment.
1
1
• After checking the height di erence, select one
Snap Ring with a suitable thickness.
Important: You can only insert one snap ring.
Inserting two or more Snap Rings may cause
the Snap Rings to slip out or make a rubbing
noise.
• Lift up the lower door and insert the Snap Ring
into the space between the Door and the Hinge.
• To avoid injury, insert or remove Snap
Rings carefully.
• Keep the Snap Rings out of the reach of
children and make sure that children do not
play with them or put them into their mouths.
• 1mm, 1.5mm, 2mm, and 2.5mm Snap
Rings come with the Refrigerator.
• If the Refrigerator is level before you load it with
food, the Refrigerator may become unbalanced
due to the weight of the food.
If this occurs, adjust the level again using the
same procedure.
• If you raise the door too far, it can rub against
the Top Cover.
Snap Rings included with the refrigerator:
1 mm
1 mm
1.5 mm
1.5 mm
2 mm
2 mm
2.5 mm
2.5 mm
CAUTION
